PZS
SURFACE MOUNT
SINGLE-PHASE FULL WAVE BRIDGE
PRV/Leg
200V
600V
SURFACE MOUNT
THROUGH-HOLE
PZ20S
PZ 20
PZ 60S
PZ 60
ELECTRICAL CHARACTERISTICS
@ 25 oC UNLESS OTHERWISE SPECIFIED
0.8Amp
Average Forward Current
1.05Volts
Max.Forward Voltage Drop@ 0.8 Amp
Max. DC Reverse Current @ PR V
10.0
A
30 Amps
(8.3 ms)
Max. Peak Surge Current
o
-55 to +150 C
Ambient Operating T emperature
Storage T emperature Range
o
-55 to +150 C
EDI reserves the rightto change these specifications at any time without notice.
