ALUMINUM ELECTROLYTIC CAPACITORS
4.5mmL Chip Type
ZS series
Chip type with 4.5mm height.
WX
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
Adapted to the RoHS directive (2002/95/EC).
High
Smaller
Bi-polarized
ZT
ZP
Temperature
Z S
Smaller
ZR
Specifications
Item
Performance Characteristics
Temperature Range
Category
–40 ~ + 85°C
4 ~ 50V
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
0.1 ~ 220µF
+
20% at 120Hz, 20°C
–
After 2 minutes' application of rated voltage leakage current is not more than 0.01 CV or 3 (µA) ,whichever is greater.
,
Measurement frequency : 120Hz Temperature : 20°C
,
Rated voltage (V)
4
6.3
10
16
25
35
50
tan
δ
tan δ (MAX.)
0.50
0.30
0.24
0.19
0.16
0.14
0.14
Measurement frequency : 120Hz
4
7
6.3
4
10
3
16
25
2
35
2
50
2
Rated voltage (V)
Stability at Low Temperature
2
4
Z–25°C / Z+20°C
Z–40°C / Z+20°C
Impedance ratio
ZT / Z20 (MAX.)
15
8
8
4
3
3
+
Capacitance change
tan δ
Within 20% of initial value
–
After 2000 hours' application of rated voltage
at 85°C,capacitors meet the characteristics
requirements listed at right.
200% or less of initial specified value
Initial specified value or less
Endurance
Shelf Life
Leakage current
After storing the capacitors under no load at 85°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
+
Capacitance change
tan δ
Within 10% of initial value
–
Resistance to soldering
heat
for 30 seconds. After removing from the hot plate and restored
at room temperature,they meet the characteristic requirements
listed at right.
Initial specified value or less
Initial specified value or less
Leakage current
Marking
Black print on the case top.
Type numbering system (Example : 16V 10 F)
µ
Chip Type
Positive
1
2
3
4
5
6
7
8
9 10 11 12 13 14
Capacitance
U Z S 1 C 1 0 0 M C L 1 G B
Plastic platform
+
Voltage
Lot No.
0.3 MAX.
C
0.2
–
Taping code
(mm)
6.3
1.8 2.1 2.4
4.3 5.3 6.6
4.3 5.3 6.6
1.0 1.3 2.2
Configuration
φD
A
B
C
E
4
5
+
Capacitance tolerance ( 20%)
–
Rated Capacitance (10µF)
Rated voltage (16V)
Series name
+0.1
–0.2
4.5
Negative
0.5 ~ 0.8
Voltage mark for 6.3V is 6V
.
Type
Dimensions
4
6.3
10
1A
16
25
35
50
V
Cap. (µF)
Code
0G
0J
1C
1E
1V
1H
0.1
0.22
0.33
0.47
1
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
221
4
1.0
2.0
2.8
4.0
8.4
4
4
4
4
2.2
3.3
4.7
4
13
4
17
20
33
4
16
27
42
52
4
18
29
46
5
10
4
23
37
49
58
5
5
6.3
22
33
4
28
37
45
70
5
33
5
6.3
6.3
6.3
4
28
33
56
96
5
5
41
52
6.3
6.3
47
4
5
6.3
100
220
5
6.3
Rated
ripple
Case size
φD (mm)
6.3
Rated Ripple (mArms) at 85°C 120Hz
Taping specifications are given in page 24.
Frequency coefficient of rated ripple current
Recommended land size, soldering by reflow are given in page 25, 26.
Please select UR(p.70), UG(p.75) series if high C/V products are reqired.
Please refer to page 3 for the minimum order quantity.
Frequency
50 Hz
120 Hz
300 Hz
1 kHz
10 kHz~
1.50
Coefficient
0.70
1.00
1.17
1.36
CAT.8100V
