8PH
SINGLE-PHASE FULL WAVE BRIDGE
8 AMPERES
FOR P.C. BOARD AND HEAT SINK MOUNTING
PRV/Leg
Type No.
50V
100V
200V
400V
600V
800V
1000V
8PH05
8PH10
8PH20
8PH40
8PH60
8PH80
8PH100
ELECTRICAL CHARACTERISTICS PER LEG
(at T
=25 C Unl ess Oth erw ise Spe cified)
A
Average Output Current. lo @65 OC Tc (Fig.1)
Amp
8
Amp
@
2.5
Max. Forward Voltage Drop, VF=1.0 V
IR
=
IF
A
A
10
Max.DC Reverse Current @ PRV,
O
Max.DC Reverse Current @ PRV,and 100 C, IR
300
Amp
300
5.8
Max.Peak Surge Current, IFSM
0 j-c
(8.3ms) (Fig.2)
oC/ W
oC
Thermal Resistance , R
Ambient Operating Temperature Range,TA
Storge TemperatureRange,T
-55 to +150
-55 to +150
oC
STG
Note 1:Derate Io by 20% for capacitive loads
EDI reserves the right to change these specifications at any time without notice
