TYNx40 Series
®
40A SCRS
STANDARD
Table 1: Main Features
Symbol
A
Value
Unit
IT(RMS)
40
A
G
K
VDRM/VRRM
IGT
600 to 1000
35
V
A
mA
DESCRIPTION
K
The TYNx40 series is suitable for applications
where in-rush current conditions are critical, such
as overvoltage crowbar protection circuits in
power supplies, in-rush current limiting circuits,
solid state relays (in back to back configuration),
welding equipment, high power motor control
circuits.
Using clip assembly technology, they provide a
superior performance in high surge current
capabilites.
A
G
TO-220AB
Table 2: Order Codes
Part Numbers
Marking
TYN640
TYN840
TYN1040
TYN640RG
TYN840RG
TYN1040RG
Table 3: Absolute Ratings (limiting values)
Symbol
Parameter
Value
40
Unit
A
IT(RMS)
Tc = 95°C
Tc = 95°C
RMS on-state current (180° conduction angle)
Average on-state current (180° conduction angle)
IT(AV)
25
A
tp = 8.3 ms
480
460
1060
ITSM
Tj = 25°C
Non repetitive surge peak on-state current
A
tp = 10 ms
²
²
I t
I t Value for fusing
A2S
tp = 10 ms Tj = 25°C
Critical rate of rise of on-state current IG =
2 x IGT , tr ≤ 100 ns
Tj = 125°C
dI/dt
F = 60 Hz
tp = 20 µs
50
A/µs
IGM
Tj = 125°C
Tj = 125°C
Peak gate current
4
1
A
PG(AV)
Average gate power dissipation
W
Tstg
Tj
- 40 to + 150
- 40 to + 125
Storage junction temperature range
Operating junction temperature range
°C
V
VRGM
Maximum peak reverse gate voltage
5
February 2006
REV. 5
1/6
