8Q512K32

型号：

8Q512K32

描述：

16Megabit SRAM MCM[ 16Megabit SRAM MCM ]

品牌：

AEROFLEX[ AEROFLEX CIRCUIT TECHNOLOGY ]

页数：

14 页

PDF大小：

138 K

下载PDF手册
Standard Products
QCOTSTM UT8Q512K32 16Megabit SRAM MCM
Data Sheet
June, 2003
FEATURES
INTRODUCTION
The QCOTSTM UT8Q512K32 Quantified Commercial
Off-the-Shelf product is a high-performance 2M byte
(16Mbit) CMOS static RAM multi-chip module (MCM),
organized as four individual 524,288 x 8 bit SRAMs with a
common output enable. Memory expansion is provided by
an active LOW chip enable (En), an active LOW output
enable (G), and three-state drivers. This device has a power-
down feature that reduces power consumption by more than
90% when deselected.
q
q
25ns maximum (3.3 volt supply) address access time
MCM contains four (4) 512K x 8 industry-standard
asynchronous SRAMs; the control architecture allows
operation as 8, 16, 24, or 32-bit data width
q
q
TTL compatible inputs and output levels, three-state
bidirectional data bus
Typical radiation performance
- Total dose: 50krads
- SEL Immune >80 MeV-cm2/mg
- LETTH(0.25) = >10 MeV-cm2/mg
- Saturated Cross Section cm2 per bit, 5.0E-9
- <1E-8 errors/bit-day, Adams 90% geosynchronous
heavy ion
Writing to each memory is accomplished by taking the chip
enable (En) input LOW and write enable ( Wn) inputs LOW.
Data on the I/O pins is then written into the location
specified on the address pins (A0 through A18). Reading
q
q
Packaging options:
from the device is accomplished by taking the chip enable
(En) and output enable (G) LOW while forcing write enable
(Wn) HIGH. Under these conditions, the contents of the
memory location specified by the address pins will appear
on the I/O pins.
- 68-lead dual cavity ceramic quad flatpack (CQFP) -
(weight 7.37 grams)
Standard Microcircuit Drawing5962-01533
- QML T and Q compliant part
The input/output pins are placed in a high impedance state
when the device is deselected (En HIGH), the outputs are
disabled (G HIGH), or during a write operation (En LOW
and Wn LOW). Perform 8, 16, 24 or 32 bit accesses by
making Wn along with En a common input to any
combination of the discrete memory die.
W3
W2
W1
W0
E2
E3
E0
E1
A(18:0)
G
512K x 8
512K x 8
512K x 8
512K x 8
DQ(31:24)
or
DQ(23:16)
or
DQ(15:3)
or
DQ(7:0)
or
DQ3(7:0)
DQ2(7:0)
DQ1(7:0)
DQ0(7:0)
Figure 1. UT8Q512K32 SRAM Block Diagram
DEVICE OPERATION
Each die in the UT8Q512K32 has three control inputs called
Enable (En), Write Enable (Wn), and Output Enable (G); 19
address inputs, A(18:0); and eight bidirectional data lines,
DQ(7:0). The device enable (En) controls device selection,
active, and standby modes. Asserting En enables the device,
causes IDD to rise to its active value, and decodes the 19 address
9
8 7 6 5 4 3 2 1 68 67 66 65 64 63 62 61
DQ0(0)
DQ1(0)
DQ2(0)
DQ3(0)
DQ4(0)
DQ5(0)
DQ6(0)
DQ7(0)
DQ0(2)
DQ1(2)
DQ2(2)
DQ3(2)
DQ4(2)
DQ5(2)
DQ6(2)
DQ7(2)
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
Top View
inputs to each memory die by selecting the 2,048,000 byte of
memory. Wn controls read and write operations. During a read
cycle, G must be asserted to enable the outputs.
V
V
SS
SS
DQ0(1)
DQ0(3)
DQ1(3)
DQ2(3)
DQ3(3)
DQ4(3)
DQ5(3)
DQ6(3)
DQ7(3)
DQ1(1)
DQ2(1)
DQ3(1)
DQ4(1)
DQ5(1)
DQ6(1)
DQ7(1)
Table 1. Device Operation Truth Table
G
Wn
X
En
1
I/O Mode
3-state
Mode
27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43
X1
X
1
Standby
0
1
0
0
Data in
3-state
Write
Read2
Read
Figure 2. 25ns SRAM Pinout (68)
0
1
0
Data out
Notes:
PIN NAMES
1. “X” is defined as a “don’t care” condition.
2. Device active; outputs disabled.
A(18:0) Address
Wn
G
WriteEnable
Output Enable
Power
READ CYCLE
DQ(7:0) Data Input/Output
A combination ofWn greater than V IH (min) withEn and G less
than VIL (max) defines a read cycle. Read access time is
En
VDD
Device Enable
measured from the latter of device enable, output enable, or valid
address to valid data output.
VSS
Ground
SRAM read Cycle 1, the Address Access is initiated by a change
in address inputs while the chip is enabled with G asserted and
Wn deasserted. Valid data appears on data outputs DQn(7:0)
after the specified tAVQV is satisfied. Outputs remain active
throughout the entire cycle. As long as device enable and output
enable are active, the address inputs may change at a rate equal
to the minimum read cycle time (tAVAV).
SRAM read Cycle 2, the Chip Enable-controlled Access is
initiated by En going active while G remains asserted, Wn
remains deasserted, and the addresses remain stable for the
entire cycle. After the specified tETQV is satisfied, the eight-bit
word addressed by A(18:0) is accessed and appears at the data
outputs DQn(7:0).
SRAM read Cycle 3, the Output Enable-controlled Access is
initiated by G going active while En is asserted, Wn is
deasserted, and the addresses are stable. Read access time is
tGLQV unless tAVQV or tETQV have not been satisfied.
2
WRITE CYCLE
TYPICAL RADIATION HARDNESS
The UT8Q512K32 SRAM incorporates features which allow
operation in a limited radiation environment.
A combination of Wn less than VIL(max) and En less than
VIL(max) defines a write cycle. The state of G is a “don’t care”
Table 2. Typical Radiation Hardness
Design Specifications1
for a write cycle. The outputs are placed in the high-impedance
state when eitherG is greater than V IH(min), or when Wn is less
than V (max).
IL
Total Dose
50
krad(Si) nominal
Errors/Bit-Day
Write Cycle 1, the Write Enable-controlled Access is defined
by a write terminated byWn going high, with En still active.
The write pulse width is defined by tWLWH when the write is
Heavy Ion
Error Rate 2
<1E-8
initiated byWn, and by tETWH when the write is initiated byEn.
Notes:
Unless the outputs have been previously placed in the high-
impedance state byG, the user must wait t WLQZ before applying
1. The SRAM will not latchup during radiation exposure under recommended
operating conditions.
2. 90% worst case particle environment, Geosynchronous orbit, 100 mils of
Aluminum.
data to the eight bidirectional pins DQn(7:0) to avoid bus
contention.
Write Cycle 2, the Chip Enable-controlled Access is defined by
a write terminated by the former ofEn or Wn going inactive.
The write pulse width is defined by tWLEF when the write is
initiated by Wn, and by tETEF when the write is initiated by the
En going active. For the Wn initiated write, unless the outputs
have been previously placed in the high-impedance state byG,
the user must wait tWLQZ before applying data to the eight
bidirectional pins DQn(7:0) to avoid bus contention.
3
1
ABSOLUTE MAXIMUM RATINGS
(Referenced to VSS
)
SYMBOL
PARAMETER
DC supply voltage
LIMITS
VDD
-0.5 to 4.6V
VI/O
TSTG
PD
Voltage on any pin
-0.5 to 4.6V
-65 to +150°C
1.0W (per byte)
+150°C
Storage temperature
Maximum power dissipation
Maximum junction temperature2
TJ
Thermal resistance, junction-to-case3
DC input current
QJC
10°C/W
II
±10 mA
Notes:
1. Stresses outside the listed absolute maximum ratings may cause permanent damage to the device. This is a stress rating only, and functional operation of the device
at these or any other conditions beyond limits indicated in the operational sections of this specification is not recommended. Exposure to absolute maximum rating
conditions for extended periods may affect device reliability and performance.
2. Maximum junction temperature may be increased to +175°C during burn-in and steady-static life.
3. Test per MIL-STD-883, Method 1012.
RECOMMENDED OPERATING CONDITIONS
SYMBOL
VDD
PARAMETER
Positive supply voltage
Case temperature range
LIMITS
3.0 to3.6V
TC
-40 to +125°C
VIN
DC input voltage
0V to VDD
4
DC ELECTRICAL CHARACTERISTICS (Pre/Post-Radiation)*
(-40°C to +125°C) (VDD = 3.3V + 0.3)
SYMBOL
PARAMETER
CONDITION
MIN
MAX
UNIT
VIH
High-level input voltage
(CMOS)
(CMOS)
2.0
V
VIL
Low-level input voltage
Low-level output voltage
Low-level output voltage
High-level output voltage
High-level output voltage
Input capacitance
0.8
0.4
V
V
VOL1
VOL2
VOH1
VOH2
IOL = 8mA, VDD =3.0V
IOL = 200mA,VDD =3.0V
IOH = -4mA,VDD =3.0V
IOH = -200mA,VDD =3.0V
¦ = 1MHz @ 0V
0.08
V
2.4
V
VDD-0.10
V
1
32
16
pF
CIN
1
Bidirectional I/O capacitance
¦ = 1MHz @ 0V
pF
CIO
IIN
Input leakage current
VSS < VIN < VDD, VDD = VDD (max)
-2
-2
2
2
mA
mA
IOZ
Three-state output leakage current
0V < VO < VDD
VDD = VDD (max)
G = VDD (max)
2, 3
Short-circuit output current
0V < VO < VDD
-90
90
mA
mA
IOS
Supply current operating
@ 1MHz
Inputs: VIL = 0.8V,
VIH = 2.0V
125
IDD(OP)
(per byte)
IOUT = 0mA
VDD = VDD (max)
IDD1(OP) Supply current operating
Inputs: VIL = 0.8V,
VIH = 2.0V
180
mA
@40MHz
(per byte)
IOUT = 0mA
VDD = VDD (max)
-40°C and
25°C
IDD2(SB) Nominal standby supply current
Inputs: VIL = V
6
mA
mA
SS
@0MHz
(per byte)
IOUT = 0mA
40
En = VDD - 0.5, VDD = VDD (max)
VIH = VDD - 0.5V
+125°C
Notes:
* Post-radiation performance guaranteed at 25°C per MIL-STD-883 Method 1019.
1. Measured only for initial qualification and after process or design changes that could affect input/output capacitance.
2. Supplied as a design limit but not guaranteed or tested.
3. Not more than one output may be shorted at a time for maximum duration of one second.
5
AC CHARACTERISTICS READ CYCLE (Pre/Post-Radiation)*
(-40°C to +125°C) (VDD = 3.3V + 0.3)
SYMBOL
PARAMETER
MIN
MAX
UNIT
1
Read cycle time
25
ns
tAVAV
tAVQV
Read access time
Output hold time
25
ns
ns
2
3
3
tAXQX
2
G-controlled Output Enable time
ns
tGLQX
tGLQV
G-controlled Output Enable time (Read Cycle 3)
G-controlled output three-state time
10
10
ns
ns
2
tGHQZ
2,3
En-controlled Output Enable time
En-controlled access time
3
ns
ns
ns
tETQX
3
25
10
tETQV
1,2,4
En-controlled output three-state time
tEFQZ
Notes: * Post-radiation performance guaranteed at 25°C per MIL-STD-883 Method 1019.
1. Functional test.
2. Three-state is defined as a 300mV change from steady-state output voltage.
3. The ET (enable true) notation refers to the falling edge of En. SEU immunity does not affect the read parameters.
4. The EF (enable false) notation refers to the rising edge ofEn. SEU immunity does not affect the read parameters.
High Z to Active Levels
Active to High Z Levels
VH - 300mV
VLOAD + 300mV
}
}
{
{
VLOAD
VLOAD - 300mV
VL + 300mV
Figure 3. 3-Volt SRAM Loading
6
tAVAV
A(18:0)
Previous Valid Data
Valid Data
tAVQV
DQn(7:0)
Assumptions:
1. En andG <V (max) and Wn >V (min)
tAXQX
IL
IH
Figure 4a. SRAM Read Cycle 1: Address Access
A(18:0)
En
tETQV
tEFQZ
tETQX
DQn(7:0)
DATA VALID
Assumptions:
1. G < V (max) and Wn > V (min)
IL
IH
Figure 4b. SRAM Read Cycle 2: Chip Enable-Controlled Access
tAVQV
A(18:0)
G
tGHQZ
tGLQX
DATA VALID
DQn(7:0)
tGLQV
Assumptions:
1. En < V (max) andW n >V (min)
IL
IH
Figure 4c. SRAM Read Cycle 3: Output Enable-Controlled Access
7
AC CHARACTERISTICS WRITE CYCLE (Pre/Post-Radiation)*
(-40°C to +125°C) (VDD = 3.3V + 0.3)
SYMBOL
PARAMETER
MIN
MAX
UNIT
1
Write cycle time
25
ns
tAVAV
tETWH
tAVET
tAVWL
tWLWH
tWHAX
tEFAX
Device Enable to end of write
20
1
ns
ns
ns
ns
ns
ns
ns
Address setup time for write (En - controlled)
Address setup time for write (Wn - controlled)
Write pulse width
0
20
2
Address hold time for write (Wn - controlled)
Address hold time for Device Enable (En - controlled)
Wn- controlled three-state time
2
2
10
tWLQZ
2
Wn - controlled Output Enable time
5
ns
tWHQX
tETEF
Device Enable pulse width (En - controlled)
Data setup time
20
15
2
ns
ns
ns
tDVWH
2
Data hold time
tWHDX
tWLEF
Device Enable controlled write pulse width
Data setup time
20
15
ns
ns
2
tDVEF
tEFDX
Data hold time
2
20
5
ns
ns
ns
tAVWH
Address valid to end of write
Write disable time
1
tWHWL
Notes:
* Post-radiation performance guaranteed at 25°C per MIL-STD-883 Method 1019.
1. Functional test performed with outputs disabled (G high).
2. Three-state is defined as 300mV change from steady-state output voltage.
8
A(18:0)
En
tAVAV
2
tAVWH
tETWH
tWHWL
Wn
tAVWL
tWLWH
tWHAX
Qn(7:0)
tWLQZ
tWHQX
Dn(7:0)
APPLIED DATA
Assumptions:
tDVWH
tWHDX
1. G < V (max). If G > V (min) then Qn(8:0) will be
IL
IH
in three-state for the entire cycle.
2. G high for t cycle.
AVAV
Figure 5a. SRAM Write Cycle 1: Write Enable - Controlled Access
9
tAVAV
3
A(18:0)
tETEF
tAVET
tEFAX
En
or
tAVET
En
tETEF
tEFAX
tWLEF
Wn
APPLIED DATA
Dn(7:0)
Qn(7:0)
tWLQZ
tDVEF
tEFDX
Assumptions & Notes:
1. G < V (max). If G > V IH (min) then Qn(7:0) will be in three-state for the entire cycle.
IL
2. Either En scenario above can occur.
3. G high for t
cycle.
AVAV
Figure 5b. SRAM Write Cycle 2: Chip Enable - Controlled Access
CMOS
90%
V
-0.05V 90%
DD
300 ohms
10%
10%
V
= 1.55
LOAD
0.5V
< 5ns
< 5ns
50pF
Input Pulses
Notes:
1. 50pF including scope probe and test socket capacitance.
2. Measurement of data output occurs at the low to high or high to low transition mid-point
(i.e., CMOS input = V /2).
DD
Figure 6. AC Test Loads and Input Waveforms
10
DATA RETENTION MODE
VDD
50%
tEFR
50%
tR
VDR > 2.0V
En
Figure 7. Low VDD Data Retention Waveform
DATA RETENTION CHARACTERISTICS (Pre/Post-Irradiation)
(1 Second Data Rentention Test)
SYMBOL
PARAMETER
MINIMUM
MAXIMUM UNIT
VDR
VDD for data retention
2.0
--
V
1,2
Data retention current (per byte)
Chip select to data retention time
Operation recovery time
--
0
2.0
mA
IDDR
1,3
ns
ns
tEFR
1,3
tAVAV
tR
Notes:
1. En = V - .2V, all other inputs = V
or V .
SS
DD
DR
o
2. Data retention current (I
) Tc = 25 C.
DDR
3. Not guaranteed or tested.
o
o
4. V = T=-40 C and 125 C.
DR
DATA RETENTION CHARACTERISTICS (Pre/Post-Irradiation)
(10 Second Data Retention Test, TC=-40oC and +125oC)
SYMBOL
PARAMETER
VDD for data retention
MINIMUM
MAXIMUM UNIT
1
3.0
3.6
V
ns
ns
VDD
2, 3
Chip select to data retention time
Operation recovery time
0
tEFR
2, 3
tAVAV
tR
Notes:
1. Performed at V
(min) and V
(max).
DD
DD
2. En = V , all other inputs = V
or V
.
SS
SS
DR
3. Not guaranteed or tested.
11
PACKAGING
Notes:
1. Package shipped with non-conductive
strip (NCS). Leads are not trimmed.
2. Total weight approx. 7.37g.
Figure 8. 68-pin Ceramic FLATPACK
12
ORDERING INFORMATION
512K32 16Megabit SRAM MCM:
UT8Q512K32 -* *
*
*
Lead Finish:
(C) Gold
=
Screening:
(P) = Prototype flow
o
o
(W) = Extended Industrial Temperature Range Flow (-40 C to +125 C)
Package Type:
(S) = 68-lead dual cavity CQFP
Device Type:
- = 25ns access, 3.3V operation
Aeroflex UTMC Core Part Number
Notes:
1. Prototype flow per UTMC Manufacturing Flows Document. Tested at 25°C only. Lead finish is GOLD ONLY.
2. Extended Industrial Temperature Range Flow per UTMC Manufacturing Flows document. Devices are tested at -40 C to +125 C. Radiation neither
tested nor guaranteed. Gold lead finish only.
o
o
13
512K32 16Megabit SRAM MCM: SMD
5962 - 01533 **
* * *
Lead Finish:
(C) Gold
=
Case Outline:
(X) 68-lead dual cavity CQFP
=
Class Designator:
(T)
(Q)
=
=
QML Class T
QML Class Q
Device Type
o
o
01 = 25ns access time, 3.3V operation, Extended Industrial Temp (-40 C to +125 C)
Drawing Number: 01533
Total Dose
(-) =none
(D) = 1E4 (10krad(Si))
(L) = 5E4 (50krad(Si)) (contact factory)
(P) = 3E4 (30krad(Si)) (contact factory)
Federal Stock Class Designator: No Options
Notes:
1. Total dose radiation must be specified when ordering. Gold lead finish only.
2. Only Extended Industrial Temperature -40C to +125C. No military temp. test available.
14
厂商 型号 描述 页数 下载

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.242371s
