MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
YXH
SERIES
YXH
105℃ High ripple current. Long Life.
◆FEATURES
•
•
•
Low impedance at 100kHz with selected materials.
Load Life : 105℃ 4000～10000hours.
RoHS compliance.
◆SPECIFICATIONS
Items
Characteristics
Category Temperature Range
－40～＋105℃
Rated Voltage Range
Capacitance Tolerance
6.3～100V.DC
±20％（20℃，120Hz）
I＝0.01CV or 3μA whichever is greater.ꢀꢀ ꢀꢀ ꢀ (After 2 minutes)
Leakage Current(MAX)
I＝Leakage Current(μA) ꢀꢀꢀꢀC＝Rated Capacitance(μF) ꢀꢀꢀꢀV＝Rated Voltage(V)
Rated Voltage
(V)
（20℃，120Hz）
6.3 10 16 25 35 50 63 100
0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08
Dissipation Factor(MAX)
(tanδ)
tanδ
When rated capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After life test with rated ripple current at conditions stated in the table below, the capacitors shall meet the following requirements.
Life Time
Case Dia
Capacitance Change
Dissipation Factor
Leakage Current
Within ±25％ of the initial value.
(hrs)
Endurance
6.3～10WV 16～100WV
Not more than 200％ of the specified value.
Not more than the specified value.
φD≦6.3
φD＝8,10 6000
φD≧12.5 8000
4000
5000
7000
10000
Rated Voltage
(V)
（120Hz）
Low Temperature Stability
Impedance Ratio(MAX)
6.3 10 16 25 35 50 63 100
Z（－25℃）/Z（20℃）
Z（－40℃）/Z（20℃）
4
8
3
6
2
4
2
3
2
3
2
3
2
3
2
3
◆MULTIPLIER FOR RIPPLE CURRENT
ꢀFrequency coefficient
Frequency
（Hz）
120
1k
10k
100k≦
6.8～33μF
39～270μF
0.42
0.50
0.70
0.73
0.77
0.80
0.85
0.90
0.92
0.94
0.96
0.98
1.00
1.00
1.00
1.00
1.00
Coefficient
330～680μF 0.55
820～1800μF 0.60
2200～18000μF 0.70
◆呼称方法ꢀPART NUMBER
□□□
YXH
□□□□□
□
□□□
□□
D×L
Rated Voltage
Series
Rated Capacitance
Capacitance Tolerance
Option
Lead Forming
Case Size
