SZ5A2.4
thru
SZ5A200
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
DESIGNER’S DATA SHEET
500mW and 800mW
2.4 – 200 VOLTS
ZENER DIODES
FEATURES:
Hermetically Sealed in Glass
Axial Lead Rated at 500 mW
Surface Mount Rated at 800 mW
Available in Axial (L), Round Tab Surface Mount (SM)
and Square Tab Surface Mount (SMS) Versions
Available to TX, TXV, and Space Levels 5/
Available in 10% and 5% Tolerances. For other Voltage
Tolerances, Contact Factory.
Maximum Ratings
Symbol
Value
Units
DIM
A
B
C
D
MIN.
.060”
.120”
1.00”
.018”
MAX
.090”
.200”
---
Nominal Zener Voltage
VZ
2.4 - 200
V
2.2 - 198
3.3 – 297
L
Zener Current
IZM
PD
mA
mW
ºC
SM, SMS
.022”
L
500
800
Continuous Power
SM, SMS
AXIAL (L)
All dimensions are prior to soldering
Top,
Tstg
Operating and Storage Temp.
-65 to +175
Thermal Resistance,
RθJL
RθJE
RθJA
250
150
300
Junction to Lead, L=3/8” (for L)
Junction to End Cap (for SM, SMS)
Junction to Ambient (for All)
ºC/W
Part Number/Ordering Information 2/
DIM
A
B
C
D
MIN.
.057”
.130”
.010”
MAX.
.067”
.146”
.022”
SZ5
__ __ __ __
└ Screening 5/ __ = Not Screened
│
│
│
│
│
│
│
│
│
│
│
└
│
│
│
│
│
│
│
│
└
│
│
│
│
└
TX = TX Level
TXV = TXV
Body to Tab Clearance: .001”
S = S Level
Package Type 4/
ROUND TAB (SM)
All dimensions are prior to soldering
L = Axial Leaded
SM = Surface Mount Round Tab
SMS = Surface Mount Square Tab
Voltage/Family
2.4 thru 200 = 2.4V thru 200V, See Table on Page 2
Voltage Tolerance
A = 10% Voltage Tolerance
B = 5% Voltage Tolerance
DIM
A
B
MIN.
.070”
.175”
.023”
MAX.
.078”
.210”
.027”
C
Body to Tab Clearance: .001”
D
SQUARE TAB (SMS) All dimensions are prior to soldering
NOTE: All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
