SURFACE MOUNT SILICON
ZENER DIODES
SZ653D - SZ65D0
VZ : 3.3 - 200 Volts
PD : 5 Watts
SMB (DO-214AA)
1.1
± 0.3
FEATURES :
* Complete Voltage Range 3.3 to 200 Volts
* High peak reverse power dissipation
* High reliability
0.22
± 0.07
2.0
±
0.1
0.15
2.3
± 0.2
* Low leakage current
3.6
±
* Nonsensitive to ESD
* Pb / RoHS Free
MECHANICAL DATA
* Case : SMB (DO-214AA) Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Lead formed for Surface mount
* Polarity : Color band denotes cathode end
* Mounting position : Any
Dimensions in millimeter
PAD LAYOUT
A
INC.
mm.
A
B
C
0.260 6.60
0.085 2.16
0.110 2.79
* Weight : 0.093 gram
C
MAXIMUM RATINGS
Rating at25 °C ambient temperature unless otherwise specified
B
Rating
Symbol
Value
Unit
W
PD
5.0
1.2
90
DC Power Dissipation at TL = 75 °C (Note1)
Maximum Forward Voltage at IF = 1.0 A
Maximum Thermal Resistance, Junction to ambient
Junction Temperature Range
VF
V
°C/W
°C
RθJA
TJ
- 55 to + 150
- 55 to + 150
Storage Temperature Range
Ts
°C
Note :
(1) TL = Lead temperature at5.0 mm2 ( 0.013 mm thick ) copper land areas.
Fig. 1 POWER TEMPERATURE DERATING CURVE
5.0
4.0
3.0
2.0
1.0
0
5.0 mm2 ( 0.013 mm thick )
copper land areas.
0
25
50
75
100
125
150
175
TL, LEAD TEMPERATURE (°C)
