MZ SERIES
PZ5CGxxxxE 0.5 KV ISOLATED 0.75 W REGULATED SINGLE OUTPUT SIP7
Available Inputs:
5, 12 and 15 VDC
Available Outputs:
5, 9, 12 and 15 VDC
Other specifications please enquire.
Electrical Specifications
(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)
Input Specifications
Voltage range
+/- 10 %
Filter
Capacitors
Isolation Specifications
Rated voltage
500 VDC
Resistance
1000 MOhm
Output Specifications
Voltage accuracy
Ripple and noise (at 20 MHz BW)
Short circuit protection
Line voltage regulation
Load voltage regulation
Temperature coefficient
General Specifications
Efficiency
+/- 3 %, max.
100 mV p-p, max.
Momentary
+/- 0.5 %
+/- 1.2 %
+/- 0,02 % / °C
50 % min.
Switching frequency
Environmental Specifications
Operating temperature (ambient)
Storage temperature
Derating
120 KHz, typ.
- 20° C to + 71° C
- 25 °C to + 125 °C
See graph
Humidity
Up to 90 %, non condensing
Free air convection
Cooling
Physical Characteristics
Dimensions
19.50 x 6.00 x 9.60 mm
0.76 x 0.24 x 0.37 inches
Non conductive black plastic
Case material
Examples of Partnumbers
PART
NO.
INPUT
VOLTAGE
(VDC)
OUTPUT
OUTPUT
CURRENT
(max. mA)
VOLTAGE
(VDC)
PZ5CG-0505E
PZ5CG-0512E
PZ5CG-0515E
PZ5CG-1205E
PZ5CG-1212E
PZ5CG-1215E
PZ5CG-1505E
PZ5CG-1512E
PZ5CG-1515E
5
5
150
5
12
15
5
63
5
50
12
12
12
15
15
15
150
63
12
15
5
50
150
63
12
15
50
