TXN/TYN 0512 ---> TXN/TYN 1012
PACKAGE MECHANICAL DATA
TO220AB Plastic
REF.
DIMENSIONS
Millimeters Inches
Min. Max. Min. Max.
A
H
G
A
B
C
D
F
G
H
I
J
L
M
N
O
P
10.00 10.40 0.393 0.409
15.20 15.90 0.598 0.625
13.00 14.00 0.511 0.551
J
I
D
B
C
6.20
3.50
2.65
4.40
3.75
1.23
0.49
2.40
4.80
1.14
0.61
6.60 0.244 0.259
4.20 0.137 0.165
2.95 0.104 0.116
4.60 0.173 0.181
3.85 0.147 0.151
1.32 0.048 0.051
0.70 0.019 0.027
2.72 0.094 0.107
5.40 0.188 0.212
1.70 0.044 0.066
0.88 0.024 0.034
F
L
O
P
M
= N =
Cooling method : by conduction (method C)
Marking : type number
Weight : 2.3 g
Recommended torque value : 0.8 m.N.
Maximum torque value : 1 m.N.
