PZX363C3V9
FIVE ELEMENT MOUNT ZENER DIODE ARRAY
SPICE MODEL: PZX363C3V9
Features
·
·
·
·
Other Zener Voltages Available Upon Request
Ultra-Small Surface Mount Package
Ideal For Transient Suppression
Lead Free, Green Package
SOT-363
A
Dim
A
Min
0.10
1.15
2.00
Max
0.30
1.35
2.20
C1
C2
C3
B
Mechanical Data
C
B
C
·
·
Case: SOT-363, Molded Plastic
A
C4
C5
D
0.65 Nominal
Case Material - Green Molding Compound
CEL-1702HF9, UL Flammability Rating
Classification 94V-0
Moisture sensitivity: Level 1 per J-STD-020A
Terminals: Finish - Matte Tin (Note 4)
Solderable per MIL-STD-202, Method 208
Lead Free Device
Orientation: See Diagram
Marking: See Page 3
Weight: 0.006 grams (approx.)
Ordering Information: See Page 3
G
H
F
0.30
1.80
¾
0.40
2.20
0.10
1.00
0.40
0.25
8°
H
·
·
K
J
M
J
K
0.90
0.25
0.10
0°
L
D
F
L
·
·
·
·
·
M
a
All Dimensions in mm
@ TA = 25°C unless otherwise specified
Maximum Ratings
Characteristic
Symbol
VF
Value
0.9
Unit
V
Forward Voltage (Note 1)
Power Dissipation
@ IF = 10mA
Pd
200
mW
°C/W
°C
RqJA
Thermal Resistance, Junction to Ambient Air (Note 3)
Operating and Storage Temperature Range (Note 3)
625
Tj, TSTG
-65 to +150
Temperature
Maximum Reverse
Current
Coefficient of
Zener Voltage
@ IZT = 5mA
Zener Voltage
Range (Note 1)
Maximum Zener Impedance
(Note 2)
(Note 1)
Type
Number
Marking
Code
VZ @ IZT = 5.0mA
ZZT @ IZT
ZZK @ IZK
IR @ VR
TC (mV/°C)
Nom (V) Min (V) Max (V)
W
mA
W
mA
1.0
mA
V
Min
Max
PZX363C3V9
KZZ
3.9
3.7
4.1
90
5.0
600
3.0
1.0
-3.5
0
Notes:
1. Short duration test pulse used to minimize self-heating effect.
2. f = 1KHz.
3. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
4. If lead-bearing terminal plating is required, please contact your Diodes Inc. sales representative for availability
and minimum order details.
DS30450 Rev. 1 - 2
1 of 3
