F-208 SUPPLEMENT
YTW–26–02–T–5–250–050
YTW–20–03–G–Q–400–085
TM
YTW–12–10–S–6–300–215
YTW
2mm HI-DENSITY STACKER SERIES
Mates with:
SPECIFICATIONS
YTQ, YTS, YTE
For complete specifications
see www.samtec.com?YTW
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
ALSO AVAILABLE
Current Rating:
3A @ 80°C ambient
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
Plating:
Sn or Au over 50µ" (1,27µm) Ni
RoHS Compliant:
Yes
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
Processing:
Choice of 4, 5 or 6 row
– F
Max Processing Temp:
230°C for 60 seconds
Lead–Free Solderable:
Wave only.
(2,00mm)
.0787" pitch
Note:
This Series is non-standard,
non-returnable.
NO. PINS
YTW
LEAD
STYLE
TAIL
SPEC
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
PER ROW
Specify
LEAD
STYLE
from
–G
–Q
= Four
Row
–“XXX”
= Stacker
Height
In inches
(0,13mm) .005"
increments
= 20µ" (0,51µm)
Gold contact area,
Gold flash on tail
02 thru 50
–5
= Five
Row
chart
–S
below.
= 30µ" (0,76µm)
Gold contact area,
Tin on tail
Example: –250
= (6,35mm)
.250"
–6
= Six
Row
Also Available
(Style –01 &
–02 not available)
06
300
2mm Shunt
–L
See 2SN Series.
= 10µ" (0,25µm)
Gold contact area,
Tin on tail
No. of
rows
x
(2,00)
.0787
–“XXX”
LEAD
STYLE
= Tail Length
In inches
OAL
Low Profile
See YTT &
TMM Series.
(8,20) .323
(9,60) .377
(13,60) .535
(14,10) .555
(15,10) .594
(17,10) .673
(19,10) .751
(11,60) .456
(15,60) .614
(10,08) .397
–01
–02
–03
–04
–05
–06
–07
–09
–10
–11
(0,13mm) .005"
increments
–T
= Tin
Example: -150
= (3,81mm) .150"
01
295
(2,00)
Right Angle
.0787
TYP
Four Row
No. of positions x (2,00) .0787
(0,51) .020 SQ
(1,27)
–“XXX”
See TMM Series.
.050 MIN
= Polarized Position
POST
(2,00)
.0787
Shrouded
Four Row
Vertical &
Right Angle
STACKER
HEIGHT
OAL
See
Chart
ROW OPTION
–Q
STACKER HEIGHT
TAIL
(3,05) .120 MIN
(2,00) .0787
See TMMS Series.
(0,00) .000 MIN
(4,06) .160 MIN
–5 & –6
