2.5/3.3V LVDS XO
UX73/UX703
Ultra Low Jitter LVDS Crystal Oscillator 7.0 x 5.0mm
Electrical Performance
Parameter
Min.
50
Typ.
Max.
320
Units
Notes
Output Frequency
MHz
3.135
2.375
3.3
2.5
3.465
2.625
75
Supply Voltage
V
See ordering options
Supply Current, Output Enabled
Supply Current, Output Disabled
Frequency Stability
mA
uA
ppm
°C
30
±50
See ordering options
See ordering options
Operating Temperature Range
Differential Output Voltage. VOD
Output Common Mode Voltage, VOS
Output Load
-40
+85
0.247
1.125
0.350
1.25
0.454
1.375
V
V
100Ω connected between outputs
Output requires termination
Measured 50% VCC
Duty Cycle
45
55
850
0.1
0.2
%
ps
ps
ps
Rise and Fall Time
Measured 20/80% of waveform
12kHz to 20 MHz frequency band, See
ordering information category 1
Jitter, Phase RMS (1-σ), Category 1
Jitter, Phase RMS (1-σ), Category 2
12kHz to 20 MHz frequency band, See
ordering information category 2
0.3
ps
Jitter, Accumulated RMS (1-σ)
7
25
ps
ps
20,000 Consecutive Periods
Jitter, pk-pk
40
100,000 random periods
Notes:
1. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (1 year at 25°C average effective ambient temperature), shock and vibration.
2. For specifications othere than those listed, please contact sales.
Output Enable / Disable Function
Parameter
Min.
Typ.
Max.
Units
V
Notes
Input Voltage (pin 1), Output Enable
0.7 VCC
or open
Output is Hi-Z
Input Voltage (pin 1), Output Disable (low power standby)
Internal Pullup Resistance
Output Disable Delay
0.3 VCC
V
50
kΩ
ns
200
2
Output Enable Delay
ms
ms
Start up Time
3
Absolute Maximum Ratings
Parameter
Min.
Typ.
Max.
Units
Notes
Storage Temperature
-55
+125
°C
For the latest product information visit: http://www.pericom.com/products/crystals-and-crystal-oscillators/
For test circuit go to: http://www.pericom.com/assets/sre/tc_lvds.pdf
For soldering reflow profile and reliability test ratings go to: http://www.pericom.com/assets/sre/reflow.pdf
For tape and reel information go to: http://www.pericom.com/assets/sre/tr_7050_xo.pdf
SaRonix-eCera™ is a Pericom® Semiconductor company
14-0007
All specifications are subject to change without notice.
•
US: +1-408-435-0800 TW: +886-3-4518888
•
www.pericom.com
UX73/UX703 Rev A
05/16/14
