SZ5706 thru SZ5890
And
SZ5110 thru SZ5227
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
DESIGNER’S DATA SHEET
Part Number/Ordering Information
__ __ __ __
5.0 WATT
6.8 – 270 VOLTS
ZENER DIODES
SZ5
└ Screening 7/
__ = Not Screened
TX = TX Level
TXV = TXV
│
│
│
│
│
│
│
│
│
│
│
│
│
└
│
│
│
│
│
│
│
│
│
└
│
│
│
│
│
└
S = S Level
Package Type
__ = Axial Leaded
SMS = Surface Mount Square Tab
K = 40 Mil Lead Diameter
DIM
A
MIN.
---
MAX
.158”
.185”
.053”
.042”
---
Voltage Code (See Table II)
06 thru 90
B
---
10 thru 27
C (__)
C (K)
D
.047”
.038”
1.00”
Tolerance Code (See Table II)
52 & 58 = 10%
51 & 57 = 5%
AXIAL(K & ___)
FEATURES:
■ Hermetically Sealed in Glass
■ Rated at 5 W
■ Available in Axial and Square Tab Surface Mount (SMS) version
■ Available to TX, TXV, and Space Levels 7/
■ Replacement for Microsemi UZ5706 and UZ5806 Series.
Note:
SSDI’s Zeners offer standard Voltage
Tolerance of ±10% and ±5%. For other Voltages and Voltage Tolerances,
contact SSDI’s Marketing Department.
Maximum Ratings (Table I)
Symbol
Value
Units
Nominal Zener Voltage
Maximum Zener Current
6.8 - 270
16 - 675
VZ
V
IZM
mA
DIM
A
B
C
D
MIN.
.155”
.190”
.020”
MAX.
Forward Surge Current
(8.3 msec Puls)
.185”
.225”
.030”
.30 - 40
5.0
IFSM
A
Continuous Power
PD
W
ºC
Body to Tab Clearance: .001”
Top
&Tstg
Operating and Storage Temp.
-65 to +175
SQUARE TAB (SMS)
All dimensions are prior to
soldering
Thermal Resistance,
__ - axial
34
45
Junction to Lead
K - axial
RθJL
RθJE
ºC/W
ºC/W
L=3/8” (Axial)
Thermal Resistance,
Junction to End Cap
(SMS)
7
NOTE: All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: Z00007G
DOC
