1T378A
Variable Capacitance Diode
Description
M-235
The 1T378A is a variable capacitance diode
designed for electronic tuning of wide-band CATV
tuners, and the super miniature package allows the
tuner miniaturization.
High capacitance ratio (C25/C28) is improved to
support guard band.
Features
• Super miniature package
Absolute Maximum Ratings (Ta=25 °C)
• Low series resistance 0.85 Ω Max. (f=470 MHz)
• Reverse voltage
• Operating temperature Topr
• Storage temperature
VR
34
V
• Large capacitance ratio 12.5
Typ. (C2/C25)
Min. (C25/C28)
–20 to +75
°C
1.03
Tstg –65 to +150 °C
• Small leakage current 10 nA Max. (VR=28 V)
• Capacitance deviation within 2 %
Applications
Electronic tuning of VHF band and wide-band
CATV tuners
Structure
Silicon epitaxial planar type diode
Electrical Characteristics
(Ta=25 °C)
Item
Reverse current
Reverse voltage
Symbol
IR
Conditions
Min.
Typ.
12.5
Max.
10
Unit
nA
V
VR=28 V
VR
IR=1 µA
34
C2
VR=2 V, f=1 MHz
VR=25 V, f=1 MHz
33.0
2.57
12.0
1.03
39.0
3.00
pF
pF
Diode capacitance
Capacitance ratio
C25
C2/C25
C25/C28
rs
Series resistance
CD=14 pF, f=470 MHz
VR=2 to 25 V, f=1 MHz
0.85
2
Ω
Capacitance deviation in a
matching group
∆C
%
The continuous 20 pieces of ∆C are guaranteed.
