Creation Date : February 07, 2019 (GMT)
AC-DC Power Supplies
RWS1500B-15New Product
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Option
Option Lineup
Please refer to here.
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
85 to 265V
120 to 340V
85% Typ.
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
15V
12.8 to 18.0V
100A
1500W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
127mm Nom.
63mm Nom.
261mm Nom.
3000g Typ.
Other
Operating Temp. Range
Cooling
-20 to 60°C
Blower fan cooling
UL60950-1
Safety Standard(Certified)
CSA C22.2 No.60950-1
EN60950-1
Safety Standard(Conformed)
Remarks
Den-an Appendix 12
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
