1 of 1
Creation Date : February 01, 2019 (GMT)
AC-DC Power Supplies
RWS50B-48
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Option
Option Lineup
Please refer to here.
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
85 to 265V
120 to 370V
88% Typ.
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
48V
43.2 to 52.8V
1.1A
52.8W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
34mm Nom.
82mm Nom.
81.5mm Nom.
230g Typ.
Other
Operating Temp. Range
Cooling
-20 to 70°C
Convection cooling
UL60950-1
Safety Standard(Certified)
CSA C22.2 No.60950-1
EN60950-1
Safety Standard(Conformed)
Remarks
Den-an Appendix 8 at 100VAC only
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
! Images are for reference only and show exemplary products.
! This PDF document was created based on the data listed on the TDK Corporation website.
! All specifications are subject to change without notice.
Copyright(c) TDK Corporation. All rights reserved.
