Creation Date : February 07, 2019 (GMT)
AC-DC Power Supplies
RWS100B-5
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Option
Option Lineup
Please refer to here.
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
85 to 265V
120 to 370V
79% Typ.
5V
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
4.5 to 5.75V
14A
70W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
39mm Nom.
94mm Nom.
108mm Nom.
400g Typ.
Other
Operating Temp. Range
Cooling
-20 to 70°C
Convection cooling
UL60950-1
CSA C22.2 No.60950-1
CSA C22.2 No.107.1-01
EN60950-1
Safety Standard(Certified)
UL508
Safety Standard(Conformed)
Remarks
Den-an Appendix 8 at 100VAC only
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
