Fuse Holders
INLINE FUSE HOLDER FOR JCASE® STYLE FUSES (Std. & LP)
Specifications
Maximum Voltage Rating:
Maximum Current Rating:
Cable Insulation
Operating Temperature Range:
Max. Fuse Insertion Force:
58V
See table below.
GXL, 125˚C
-40˚C to +125˚C
49N
Ordering Information
Part Number
Package Size
0FHJxxxxG
FHJCxxxxG
HLJCxxxxG
0FHJxxxxL
FHJCxxxxL
HLJCxxxxL
250
250
250
50
50
50
Description
This product is an Inline fuse holder for use with either standard or
Low Profile JCASE® fuses, 20A - 60A. It offers size and weight
savings compared to MAXI® fuseholders, and has an optional
protective cover for splash resistance. Standard product will have
two 102mm red wire leads. Wire length and insulation color can
be customized upon request. Tinned wires also available upon
request. All customizations have minimum order requirements.
Contact Littelfuse sales representative for details.
There are two available mounting options: One version with
mounting brackets, and one without.
Ratings
Part Number
Description
Cover
Mounting
Wire Size
Fuse Rating
—
—
0FHJ1001_
0FHJ1002_
0FHJ2001_
0FHJ2002_
FHJC1001_
FHJC1002_
FHJC2001_
FHJC2002_
HLJC1001_
HLJC1002_
HLJC2001_
HLJC2002_
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Standard JCASE Holder
Low Profile JCASE Holder
Low Profile JCASE Holder
Low Profile JCASE Holder
Low Profile JCASE Holder
None
None
None
None
Yes
10AWG
8AWG
10AWG
8AWG
10AWG
8AWG
10AWG
8AWG
10AWG
8AWG
10AWG
8AWG
40 A max
60 A max
40 A max
60 A max
40 A max
60 A max
40 A max
60 A max
40 A max
60 A max
40 A max
60 A max
Mounting Bracket
Mounting Bracket
—
—
Yes
Yes
Mounting Bracket
Yes
Mounting Bracket
—
—
Yes
Yes
Yes
Mounting Bracket
Yes
Mounting Bracket
