POWR-GARD® Fuse Datasheet
JTD SERIES INDICATOR® POWR-PRO® FUSES
8
600 Vac • Time Delay • /10-600 A
Specifications
Voltage Ratings
AC: 600 V
DC: 300 V ( ⁄ –100 A)
8
10
500 V (110–600 A)
⁄ –600 A
8
10
Amperage Range
Interrupting Rating
AC: 200 kA rms symmetrical
300kA rms symmetrical
(Littelfuse self-certified)
DC: 20 kA
Material
Body: Melamine
Caps: Nickel-plated Bronze ( ⁄ –60 A)
Brass (70–200 A)
8
10
Brass Cap with Copper Blade (225–600 A)
AC: Standard 248-8, Class J
UL Listed (File: E81895)
Approvals
CSA Certified (File: LR29862)
DC: Littelfuse self-certified
Mexico
Country of Origin
Description
The Littelfuse POWR-PRO® JTD_ID Indicator Class J
fuse provides visual blown fuse indication and maximum
Ordering Information
protection in a compact package.The current-limiting
time delay JTD_ID offers a patented design which
reduces nuisance fuse openings.
AMPERAGE RATINGS
8
1
1
10
4
2
2
⁄
2 ⁄
4 ⁄
10
12
15
35
40
45
50
60
70
80
90
225
250
300
350
400
450
500
600
–
–
–
–
–
–
1
Features/Benefits
• POWR-PRO® Performance
• Current-Limiting
• IECType 2 Protection
• Indication and non-indication version available
• Indicating and DIN mount holders available
1
2 ⁄
5
100
110
125
150
175
200
1
8
6
4
2
10
10
1 ⁄
2 ⁄
3
5 ⁄
6
1
1
2
1 ⁄
17 ⁄
6
2
10
10
10
2
1 ⁄
3 ⁄
7
8
9
20
25
30
8
1
1 ⁄
3 ⁄
4
2
CATALOG
NUMBER
JTD60ID
ORDERING
NUMBER
0JTD060.TXID
Applications
• Fused combination motor controllers and motor
control centers
TYPE
INDICATING
NON-INDICATING
SERIES AMPERAGE
JTD_ID
JTD
60
60
JTD60
0JTD060.T
• Transformer protection
• Protection for series rated molded case
circuit-breaker panels
• General purpose circuits
Web Resources
Time-current curves, data sheets and additional technical
information: littelfuse.com/jtd
Recommended Fuse Holders
LFJ60 Series
LFPSJ Series ( ⁄ –60 A)
8
10
© 2016 Littelfuse POWR-GARD® Products
Rev: 1-B-042116
1 of 3
