1 of 1
Creation Date : January 31, 2019 (GMT)
AC-DC Power Supplies
RWS600B-24/RFO
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Remote ON/OFF control
Remote sensing
Option
Low output voltage (LV) signal
Parallel operation
Option Lineup
Please refer to here.
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
85 to 265V
120 to 330V
88.5% Typ.
24V
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
21.6 to 27.6V
25A
600W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
61mm Nom.
120mm Nom.
190mm Nom.
1600g Typ.
Other
Operating Temp. Range
Cooling
-20 to 70°C
Blower fan cooling
UL60950-1
CSA C22.2 No.60950-1
CSA C22.2 No.107.1-01
EN60950-1
Safety Standard(Certified)
Safety Standard(Conformed)
UL508
Den-an Appendix 8 at 100VAC only
! Images are for reference only and show exemplary products.
! This PDF document was created based on the data listed on the TDK Corporation website.
Remarks
! All specifications are subject to change without notice.
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
Copyright(c) TDK Corporation. All rights reserved.
