Crystal Clock Oscillator
NZ2520SEA
High-precision Crystal Clock Oscillator
Application
■
● WiLAN, WiMAX, Bluetooth, PLC, UWB, Car-electronics connection.
Features
■
This device is a new SPXO of hold over frequency tolerance as tight as
±15×10–6(–40 to +85°C) by building a temperature compensating circuit in it.
CMOS output despite temperature compensated circuit. This device reduces harmonics level
to prevent the interference with the radio frequency by the wireless communication use.
● Overall Frequency Tolerance Max. ±15×10–6 at –40 to +85°C.
● Harmonics level reduce.
● Conventional ratio about -17dBm at Output 40MHz, VCC 2.8V, 2.4GHz band.
● Package Size : 2.5 × 2.0 × 0.9mm
Absolute maximum rating
Supply Voltage (VCC) –0.6 to +6.0 V
Storage Temperature Range –55 to +125 °C
Specifications
■
Model
NZ2520SEA
Item
Output Specification
CMOS
2.75 ≤ F ≤ 54
±15
Nominal Frequency Range
Overall Frequency Tolerance *1
Operating Temperature Range
Supply Voltage
(MHz)
×10–6
(
)
(°C)
(V)
–40 to +85
+1.8 to +3.3
3.5 to 8.0
Current
During Operation +25 °C
During Standby +25 °C
(mA)
(μA)
(V)
Consumption
Max.
10
VOL Max. / VOH Min.
Tr Max. / Tf Max.
Symmetry Min. to Max.
Load (CL) Max.
0.2 VCC / 0.8 VCC
5 / 5 ( at 0.2 to 0.8VCC )
45 to 55 ( at 1/2VCC )
15
(ns)
(%)
(pF)
(ms)
Start-up Time Max.
Standby function
10
Available (Three-state)
*1: Inclusive of +25°C tolerance, temp. characteristics, and supply voltage change.
Dimensions
Output Waveform <CMOS>
■
■
mm
2.500 0.100
Tf
Tr
Terminal land connections
VOH
#1 STAND-BY #4
VCC
N.C
N.C
0.8VCC
1/2VCC
#2
GND
#5
#6
#3 OUTPUT
●
0.2VCC
0V
0.600
VOL
t
T
Bypass capacitor
(ex.0.01μF)
Symmetry = t/T × 100 [%]
1.705
Resist
#3
#4
#1
#1 #5
#4 #6
#2
#3
Standby Function
■
#1 Input
#3 Output
Operating
0.400
0.745
Level H (0.8 VCC ≤ VIH ≤ VCC)
or OPEN
0.950
0.950
0.860
#2
Level L (VIL ≤ 0.2 VCC)
High impedance
