Crystal Clock Oscillator
NZ2520SHA
Automotive safety
Application
■
For Automotive safety (e.g., Millimeter wave radar or Image processing for self-driving)
Features
■
● High quality and high reliability design for Automotive safety
● Conforms to AEC-Q100/200.
● Supports a wide frequency range. (1.5 to 125MHz)
● Supports a wide temperature range from –40 to +125°C.
● Compact and light. Dimensions : 2.5 x 2.0 x 0.9 mm, weight : 0.02 g.
● Taped units enable automatic mounting IR Reflow (lead free) is possible.
● Lead-free.
Absolute maximum rating
Supply Voltage (VCC) -0.3 to +4.0 V
Storage Temperature Range -55 to +125 °C
● Output Specification : CMOS
Specifications
■
Model
NZ2520SHA
Item
Output Specification
CMOS
Nominal Frequency Range
Overall Frequency Tolerance
Operating Temperature Range
Supply Voltage
(MHz)
×10–6
1.5 ≤ F ≤ 80
2.5 to 9.0
80 < F ≤ 125
9.5 to 20
(
)
±100
(°C)
(V)
–40 to +125
+1.8 to +3.3
Current
During Operation +25 °C
(mA)
(μA)
(V)
Consumption
Max.
During Standby
+25 °C
20
VOL Max. / VOH Min.
0.1 VCC / 0.9 VCC
0.2 VCC / 0.8 VCC
+1.8 V
6 / 6 ( at 0.1 VCC to 0.9 VCC )
5 / 5 ( at 0.1 VCC to 0.9 VCC )
3 / 3 ( at 0.2 VCC to 0.8 VCC )
3 / 3 ( at 0.2 VCC to 0.8 VCC )
Tr Max. / Tf Max.
(ns)
+2.5 to +3.3V
Symmetry Min. to Max.
Load (CL) Max.
(%)
(pF)
(ms)
45 to 55
15
4
Start-up Time Max.
Standby function
Available (Three-state)
Dimensions
Output Waveform <CMOS>
■
■
Nominal Frequency Range : 1.5 ≤ F ≤ 80MHz
Tf
mm
2.50 0.ꢀ0
Tr
Terminal land connections
V
OH
#ꢀ
#2
#3
#4
STAND-BY
GND
0.9VCC
1/2VCC
0.1VCC
OUTPUT
0.6
V
CC
VOL
0V
t
T
Land pattern (Typical)
ꢀ.0
Symmetry = t/T × 100 [%]
0.8 0.ꢀ
#ꢀ
#3
#4
#2
Nominal Frequency Range : 80 < F ≤ 125MHz
Tf
Tr
#4
#3
#ꢀ
#2
ꢀ.65 0.ꢀ
ꢀ.65
VOH
Cby=0.0ꢀμF
0.8VCC
1/2VCC
Mount an approx. 0.0ꢀ μF bypass capacitor between VCC and GND
(close to the product)
0.2VCC
0V
Standby Function
■
VOL
t
#1 Input
#3 Output
T
Level H (0.7 VCC ≤ VIH ≤ VCC)
or OPEN is selected.
Oscillation output ON
High impedance
Symmetry = t/T × 100 [%]
Level L (VIL ≤ 0.3 VCC) is selected.
1803D_NZ2520SHA_e
