Crystal Clock Oscillator
NZ2520SJ
Low current consumption Type
Application
■
● For Smartphones, Tablet computers, notebook PC, DSC, etc.
Features
■
● External configuration size is 2.5 x 2.0 x 0.9mm (weight of 0.02g),
and is micro light weight.
● Low current consumption (Max. 0.7mA, @40MHz, +1.8V, No-load).
● Lead-free.
Absolute maximum rating
Supply Voltage (VCC) -0.3 to +4.0 V
Storage Temperature Range -55 to +125 °C
Specifications
■
Model
NZ2520SJ
Item
Output Specification
CMOS
5 ≤ F ≤ 40
Nominal Frequency Range
Overall Frequency Tolerance *1
Operating Temperature Range
Supply Voltage [VCC]
(MHz)
×10–6
(
)
± 30
(°C)
(V)
–40 to +85
+1.8 ± 0.18
0.55 to 0.70
0.82 to 1.78
10
+25 °C, No-load
+25 °C, 15pF
During
Current
Consumption
Max.
(mA)
operation*2
During standby +25 °C, No-load/15pF (μA)
VOL Max. / VOH Min.
Tr Max. / Tf Max.
(V)
(ns)
(%)
0.1 VCC / 0.9 VCC
8/8 (at 0.1VCC to 0.9VCC)
45 to 55 (at 0.5VCC)
15
Symmetry Min. to Max.
Load (CL) Max.
(pF)
(ms)
Start-up Time Max.
Standby function
4
Available (Three-state)
NSA3608A
Specification Number
*1 : Frequency Tolerance (+25°C), Frequency/Temperature characteristics, Frequency/Voltage characteristics.
*2 : Consumption current at the time of loading capacity(CLOUT)on an output ICC (CLOUT) is consumption current(ICC) at the time of no-load, and output frequency.
(FOUT) It can ask by the following formula.
ICC(CLOUT)[mA]=ICC[mA]+CLOUT[pF]×VCC[V]×FOUT[MHz] 10-3
・
Dimensions
Output Waveform <CMOS>
■
■
mm
2.50 0.ꢀ0
Tf
Tr
Terminal land connections
V
OH
#ꢀ
#2
#3
#4
STAND-BY
GND
0.9VCC
1/2VCC
0.1VCC
OUTPUT
0.6
V
CC
VOL
0V
t
T
Land pattern (Typical)
ꢀ.0
Symmetry = t/T × 100 [%]
0.8 0.ꢀ
#3
#4
#ꢀ
#4
#2
Standby Function
■
#1 Input
#3 Output
#ꢀ
#2
#3
Level H (0.7 VCC ≤ VIH ≤ VCC)
or OPEN is selected.
ꢀ.65 0.ꢀ
ꢀ.65
Cby=0.0ꢀμF
Oscillation output ON
High impedance
Mount an approx. 0.0ꢀ μF bypass capacitor between VCC and GND
(close to the product)
Level L (VIL ≤ 0.3 VCC) is selected.
Please specify the model name, frequency, and specification number when you order products.
For further questions regarding specifications, please feel free to contact us.
1803C_NZ2520SJ_e
