2.5V LVDS, 1:6 Clock Buffer Terabuffer II
IDT8R9306I
DATASHEET
General Description
Features
The IDT8R9306I 2.5V differential clock buffer is a user-selectable
differential input to six LVDS outputs. The fanout from a differential
input to six LVDS outputs reduces loading on the preceding driver
and provides an efficient clock distribution network. The IDT8R9306I
can act as a translator from a differential HSTL, eHSTL, LVPECL
(2.5V), LVPECL (3.3V), CML, or LVDS input to LVDS outputs. A
single-ended 3.3V, 2.5V LVTTL input can also be used to translate to
LVDS outputs. The redundant input capability allows for an
asynchronous change-over from a primary clock source to a
secondary clock source. Selectable reference inputs are controlled
by SEL.
• Guaranteed low skew: 40ps (maximum)
• Very low duty cycle distortion: <125ps (maximum)
• High speed propagation delay: <1.75ns (maximum)
• Up to 1GHz operation
• Selectable inputs
• Hot insertable and over-voltage tolerant inputs
• 3.3V/2.5V LVTTL, HSTL eHSTL, LVPECL (2.5V), LVPECL (3.3V),
CML or LVDS input interface
• Selectable differential inputs to six LVDS outputs
• Power-down mode
• 2.5V VDD
• -40°C to 85°C ambient operating temperature
• Available in VFQFPN package
The IDT8R9306I outputs can be asynchronously enabled/disabled.
When disabled, the outputs will drive to the value selected by the GL
pin. Multiple power and grounds reduce noise.
Applications
• Clock distribution
Pin Assignment
21 20 19 18 17 16 15
nc 22
VDD
14
nQ5 23
13 nQ3
24
Q3
Q5
12
11
GND
nQ6 25
nQ2
26
10 Q2
Q6
27
VDD
VDD
GL
9
8
SEL 28
1
2
3
4
5
6
7
IDT8R9306I
28-Lead VFQFPN
6mm x 6mm x 0.9mm package body
EPad 4.8mm x 4.8mm
NL Package
Top View
IDT8R9306NLI REVISION D AUGUST 21, 2013
1
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Block Diagram
GL
nG
Q1
OUTPUT
CONTROL
nQ1
nPD
Q2
OUTPUT
CONTROL
nQ2
A1
1
0
nA1
Q3
OUTPUT
CONTROL
nQ3
A2
Q4
OUTPUT
CONTROL
nA2
nQ4
Q5
OUTPUT
SEL
CONTROL
nQ5
Q6
OUTPUT
CONTROL
nQ6
IDT8R9306NLI REVISION D AUGUST 21, 2013
2
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Pin Descriptions and Characteristics
Table 1. Pin Descriptions
Name
Type
Description
A[1:2]
Input
Input
Adjustable (1, 4) Clock input. A[1:2] is the "true" side of the differential clock input.
Complementary clock inputs. nA[1:2] is the complementary side of A[1:2]. For LVTTL
single-ended operation, nA[1:2] should be set to the desired toggle voltage for A[1:2]:
3.3V LVTTL VREF = 1650mV
nA[1:2]
Adjustable (1, 4)
2.5V LVTTL VREF = 1250mV
Gate control for differential outputs Q[1:6] and nQ[1:6]. When nG is LOW, the differential
nG
GL
Input
Input
LVTTL
LVTTL
outputs are active. When nG is HIGH, the differential outputs are asynchronously driven to
the level designated by GL(2). See Table 3A.
Specifies output disable level. If HIGH, "true" outputs disable HIGH and "complementary"
outputs disable LOW. If LOW, "true" outputs disable LOW and "complementary" outputs
disable HIGH. See Table 3A.
Q[1:6]
Output
Output
LVDS
LVDS
Clock outputs.
nQ[1:6]
Complementary clock outputs.
Reference clock select. When LOW, selects A2 and nA2. When HIGH, selects A1 and nA1.
See Table 3B.
SEL
nPD
Input
Input
LVTTL
LVTTL
Power-down control. Shuts off entire chip. If LOW, the device goes into low power mode.
Inputs and outputs are disabled. Both "true" and “complementary” outputs will pull to VDD.
Set HIGH for normal operation.(3)
VDD
GND
nc
Power
Power
Power supply for the device core and inputs.
Power supply return for all power.
No connect; recommended to connect to GND.
NOTES:
1
Inputs are capable of translating the following interface standards:
Single-ended 3.3V and 2.5V LVTTL levels
Differential HSTL and eHSTL levels
Differential LVPECL (2.5V) and LVPECL (3.3V) levels
Differential LVDS levels
Differential CML levels
2.
3.
4.
Because the gate controls are asynchronous, runt pulses are possible. It is the user's responsibility to either time the gate control
signals to minimize the possibility of runt pulses or be able to tolerate them in down stream circuitry.
It is recommended that the outputs be disabled before entering power-down mode. It is also recommended that the outputs remain
disabled until the device completes power-up after asserting nPD.
The user must take precautions with any differential input interface standard being used in order to prevent instability when there is
no input signal.
Table 2. Pin Characteristics, TA = +25°C, F = 1.0MHz)
Symbol
Parameter
Test Conditions
Minimum
Typical
Maximum
Units
CIN
Input Capacitance
3
pF
NOTE: This parameter is measured at characterization but not tested.
IDT8R9306NLI REVISION D AUGUST 21, 2013
3
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Function Tables
Table 3A. Gate Control Output Table
Control Output
Outputs
GL
0
nG
0
Q[1:6]
Toggling
LOW
nQ[1:6]
Toggling
HIGH
0
1
1
0
Toggling
HIGH
Toggling
LOW
1
1
Table 3B. Input Selection Table
Selection SEL pin
Inputs
A2, nA2
A1, nA1
0
1
Absolute Maximum Ratings
NOTE: Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress
specifications only. Functional operation of product at these conditions or any conditions beyond those listed in the DC Characteristics or AC
Characteristics is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
Item
Rating
Power Supply Voltage, VDD
Input Voltage, VI
-0.5V to +3.6V
-0.5V to +3.6V
Output Voltage, VO
Not to exceed 3.6V
-0.5 to VDD +0.5V
Storage Temperature, TSTG
Junction Temperature, TJ
-65C to 150C
150C
Recommended Operating Range
Symbol
TA
Description
Minimum
Typical
+25
Maximum
+85
Units
C
Ambient Operating Temperature
Internal Power Supply Voltage
-40
2.3
VDD
2.5
2.7
V
IDT8R9306NLI REVISION D AUGUST 21, 2013
4
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
DC Electrical Characteristics
Table 4A. LVDS Power Supply DC Characteristics , T = -40°C to 85°C
(1)
A
Symbol
Parameter
Test Conditions
Minimum
Typical(2)
Maximum
Units
VDD = Max.,
All Input Clocks = LOW(2)
Outputs enabled
Quiescent VDD Power Supply
Current
IDDQ
;
240
mA
Total Power VDD Supply
Current
VDD = 2.7V;
REFERENCE Clock = 1GHz
ITOT
IPD
250
5
mA
mA
F
Total Power Down Supply
Current
nPD = LOW
NOTE 1: These power consumption characteristics are for all the valid input interfaces and cover the worst case conditions.
NOTE 2: The true input is held LOW and the complementary input is held HIGH.
(1)
Table 4B. LVCMOS/LVTTL DC Characteristics , T = -40°C to 85°C
A
Symbol
IIH
Parameter
Test Conditions
VDD = 2.7V
Minimum
Typical(2)
Maximum
Units
µA
µA
V
Input High Current
Input Low Current
Clamp Diode Voltage
DC Input Voltage
DC Input High Voltage
DC Input Low Voltage
5
5
IIL
VDD = 2.7V
VIK
VDD = 2.3V, IIN = -18mA
-0.7
-1.2
3.6
VIN
-0.3
1.7
V
VIH
V
VIL
0.7
V
DC Input Threshold Crossing
Voltage
VTHI
VDD/2
V
3.3V LVTTL
2.5V LVTTL
1.65
1.25
V
V
Single-Ended Reference
Voltage (3)
VREF
NOTE 1: See Recommended Operating Range table.
NOTE 2: Typical values are at VDD = 2.5V, +25°C ambient.
NOTE 3: For A[1:2] single-ended operation, nA[1:2] is tied to a DC reference voltage.
(1)
Table 4C. Differential DC Characteristics , T = -40°C to 85°C
A
Symbol
IIH
Parameter
Test Conditions
VDD = 2.7V
Minimum
Typical(2)
Maximum
Units
µA
µA
V
Input High Current
Input Low Current
Clamp Diode Voltage
DC Input Voltage
DC Differential Voltage(3)
5
5
IIL
VDD = 2.7V
VIK
VDD = 2.3V, IIN = -18mA
-0.7
-1.2
3.6
VIN
-0.3
0.1
V
VDIF
V
DC Common Mode Input
Voltage
VCM
0.05
VDD
V
NOTE 1: See Recommended Operating Range table.
NOTE 2: Typical values are at VDD = 2.5V, +25°C ambient.
NOTE 3: VDIF specifies the minimum input differential voltage (VTR - VCP) required for switching where VTR is the "true" input level and VCP is
the "complement" input level. The DC differential voltage must be maintained to guarantee retaining the existing HIGH or LOW input. The AC
differential voltage must be achieved to guarantee switching to a new state.
NOTE 4: VCM specifies the maximum allowable range of (VTR + VCP) /2.
IDT8R9306NLI REVISION D AUGUST 21, 2013
5
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
(1)
Table 4D. LVDS DC Characteristics , T = -40°C to 85°C
A
Symbol
Parameter
Test Conditions
Minimum
Typical(2)
Maximum
Units
Differential Output Voltage for
the
VOT(+)
247
454
mV
True Binary State
Differential Output Voltage for
the
False Binary State
VOT(–)
VOT
VOS
247
454
50
mV
mV
V
Change in VOT Between
Complementary Output
States
Output Common Mode
Voltage
(Offset Voltage)
1.125
1.2
1.375
50
Change in VOS Between
Complementary Output
States
VOS
mV
IOS
Outputs Short Circuit Current
VOUT+ and VOUT– = 0V
12
6
24
12
mA
mA
Differential Outputs Short
Circuit Current
IOSD
VOUT+ = VOUT–
NOTE 1: See Recommended Operating Range table.
NOTE 2: Typical values are at VDD = 2.5V, +25°C ambient.
AC Electrical Characteristics
Table 5A. HSTL Differential Input AC Characteristics, T = -40°C to 85°C
A
Symbol
VDIF
VX
Parameter
Input Signal Swing(1)
Differential Input Signal Crossing Point(2)
Value
1
Units
V
750
50
mV
%
DH
Duty Cycle
VTHI
tR / tF
Input Timing Measurement Reference Level(3)
Input Signal Edge Rate(4)
Crossing Point
2
V
V/ns
NOTE 1. The 1V peak-to-peak input pulse level is specified to allow consistent, repeatable results in an automatic test equipment (ATE)
environment. This device meets the VDIF (AC) specification under actual use conditions.
NOTE 2. A 750mV crossing point level is specified to allow consistent, repeatable results in an automatic test equipment (ATE) environment.
This device meets the VX specification under actual use conditions.
NOTE 3. In all cases, input waveform timing is marked at the differential cross-point of the input signals.
NOTE 4. The input signal edge rate of 2V/ns or greater is to be maintained in the 20% to 80% range of the input waveform.
IDT8R9306NLI REVISION D AUGUST 21, 2013
6
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Table 5B. eHSTL AC Differential Input Characteristics, T = -40°C to 85°C
A
Symbol
VDIF
VX
Parameter
Input Signal Swing(1)
Differential Input Signal Crossing Point(2)
Value
Units
V
1
900
mV
%
DH
Duty Cycle
50
VTHI
tR / tF
Input Timing Measurement Reference Level(3)
Input Signal Edge Rate(4)
Crossing Point
2
V
V/ns
NOTE 1: The 1V peak-to-peak input pulse level is specified to allow consistent, repeatable results in an automatic test equipment (ATE)
environment. This device meets the VDIF (AC) specification under actual use conditions.
NOTE 2: A 900mV crossing point level is specified to allow consistent, repeatable results in an automatic test equipment (ATE) environment.
This device meets the VX specification under actual use conditions.
NOTE 3: In all cases, input waveform timing is marked at the differential cross-point of the input signals.
NOTE 4: The input signal edge rate of 2V/ns or greater is to be maintained in the 20% to 80% range of the input waveform.
Table 5C. LVPECL (2.5V) and LVPECL (3.3V) Differential Input AC Characteristics, T = -40°C to 85°C
A
Symbol Parameter
Maximum
Units
mV
mV
mV
%
VDIF
Input Signal Swing(1)
732
LVPECL
LVPECL
1082
VX
Differential Input Cross Point Voltage(2)
1880
DH
Duty Cycle
50
VTHI
tR / tF
Input Timing Measurement Reference Level(3)
Input Signal Edge Rate(4)
Crossing Point
2
V
V/ns
NOTE 1: The 732mV peak-to-peak input pulse level is specified to allow consistent, repeatable results in an automatic test equipment (ATE)
environment. This device meets the VDIF (AC) specification under actual use conditions.
NOTE 2: A 1082mV LVPECL (2.5V) and 1880 LVPECL (3.3V) crossing point level is specified to allow consistent, repeatable results in an
automatic test equipment (ATE) environment. This device meets the VX specification under actual use conditions.
NOTE 3: In all cases, input waveform timing is marked at the differential cross-point of the input signals.
NOTE 4: The input signal edge rate of 2V/ns or greater is to be maintained in the 20% to 80% range of the input waveform.
Table 5D. LVDS Differential Input AC Characteristics, T = -40°C to 85°C
A
Symbol Parameter
Maximum
Units
mV
V
VDIF
VX
Input Signal Swing(1)
Differential Input Cross Point Voltage(2)
400
1.2
DH
Duty Cycle
50
%
VTHI
tR / tF
Input Timing Measurement Reference Level(3)
Input Signal Edge Rate(4)
Crossing Point
2
V
V/ns
NOTE 1: The 400mV peak-to-peak input pulse level is specified to allow consistent, repeatable results in an automatic test equipment (ATE)
environment. This device meets the VDIF (AC) specification under actual use conditions.
NOTE 2: A 1.2V crossing point level is specified to allow consistent, repeatable results in an automatic test equipment (ATE) environment. This
device meets the VX specification under actual use conditions.
NOTE 3: In all cases, input waveform timing is marked at the differential cross-point of the input signals.
NOTE 4: The input signal edge rate of 2V/ns or greater is to be maintained in the 20% to 80% range of the input waveform.
IDT8R9306NLI REVISION D AUGUST 21, 2013
7
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
(1)
Table 5E. AC Differential Input Characteristics , T = -40°C to 85°C
A
Symbol
VDIF
VX
Parameter
Minimum
0.1
Typical
Maximum
3.6
Units
V
AC Differential Voltage(2)
Differential Input Cross Point Voltage
Common Mode Input Voltage Range(3)
Input Voltage
0.05
VDD
V
VCM
VIN
0.05
VDD
V
-0.3
3.6
V/ns
NOTE 1: The output will not change state until the inputs have crossed and the minimum differential voltage range defined by VDIF has been
met or exceeded.
NOTE 2: VDIF specifies the minimum input voltage (VTR – VCP) required for switching where VTR is the “true” input level and VCP is the
“complement” input level. The AC differential voltage must be achieved to guarantee switching to a new state.
NOTE 3: IVCM specified the maximum allowable range of (VTR + VCP) /2.
(1,5)
Table 5F. AC Characteristics
, T = -40°C to 85°C
A
Symbol
Parameter
Test Conditions
Minimum
Typical
Maximum
Units
Same Device Output Pin-to-Pin
Skew (2)
tsk(o)
40
ps
tsk(p)
Pulse Skew(3)
Part-to-Part Skew(4)
125
300
ps
ps
tsk(pp)
25MHz, Integration Range
12kHz – 10MHz
0.541
0.159
0.185
ps
ps
ps
125MHz,IntegrationRange
12kHz – 20MHz
tJIT
RMS Additive Phase Jitter
156.25MHz, Integration
Range 12kHz – 20MHz
tpLH
tpHL
fo
Propagation Delay, Low-to-High
Propagation Delay, High-to-Low
Frequency Range(6)
1.25
1.25
1.75
1.75
1
ns
ns
A Crosspoint to Qx, nQx
Crosspoint
GHz
Output Gate Enable Crossing
tPGE
3.5
3.5
100
ns
ns
µS
V
THI-to-Qx, nQx Crosspoint
Output Gate Enable Crossing
VTHI-to-Qx, nQx Crosspoint Driven to
tPGD
GL Designated Level
nPD Crossing VTHI-to-Qx = VDD
nQx = VDD
,
tPWRDN
Output Gate Disable Crossing VTHI to
nQx Driven to GL Designated Level
Output Rise.Fall Time(6)
tPWRUP
tR / tF
100
600
µS
ps
125
NOTE: Electrical parameters are guaranteed over the specified ambient operating temperature range, which is established when the device is
mounted in a test socket with maintained transverse airflow greater than 500 lfpm. The device will meet specifications after thermal equilibrium
has been reached under these conditions.
NOTE 1: AC propagation measurements should not be taken within the first 100 cycles of startup.
NOTE 2: Skew measured between crosspoints of all differential output pairs under identical input and output interfaces, transitions and load
conditions on any one device.
NOTE 3: Skew measured is the difference between propagation delay times tpHL and tpLH of any differential output pair under identical input
and output interfaces, transitions and load conditions on any one device.
NOTE 4: Skew measured is the magnitude of the difference in propagation times between any single differential output pair of two devices,
given identical transitions and load conditions at identical VDD levels and temperature.
NOTE 5: All parameters are tested with a 50% input duty cycle.
NOTE 6: Guaranteed by design but not production tested.
IDT8R9306NLI REVISION D AUGUST 21, 2013
8
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Differential AC Timing Waveforms
Output Propagation and Skew Waveforms
1/fo
+ VDIF
V
DIF = 0
A[1:2] - nA[1:2]
- VDIF
t
PHL
t
PLH
+ VDIF
V
DIF = 0
- VDIF
Qn - nQn
t
SK(O)
t
SK(O)
+ VDIF
V
DIF = 0
- VDIF
Qm - nQm
NOTE 1: Pulse skew is calculated using the following expression:
tsk(p) = |tpHL – tpLH
|
Note that the tpHL and tpLH shown above are not valid measurements for this calculation because they are not taken from the same pulse.
NOTE 2: AC propagation measurements should not be taken within the first 100 cycles of startup.
Differential Gate Disabled/Enable Showing Runt Pulse Generation
+ VDIF
VDIF = 0
- VDIF
A[1:2] - nA[1:2]
VIH
VTHI
VIL
GL
tPLH
VIH
VTHI
VIL
nG
tPGD
tPGE
+ VDIF
VDIF = 0
- VDIF
Qn - nQn
NOTE 1: As shown, it is possible to generate runt pulses on gate disable and enable of the outputs. It is the user’s responsibility to time the nG
signal to avoid this problem.
IDT8R9306NLI REVISION D AUGUST 21, 2013
9
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Power Down Timing
+VDIF
VDIF=0
-VDIF
A1 - nA1
+VDIF
VDIF=0
-VDIF
A2 - nA2
nG
VIH
VTHI
VIL
VIH
VTHI
VIL
nPD
+VDIF
VDIF=0
-VDIF
Qn - nQn
NOTE 1: It is recommended that outputs be disabled before entering power-down mode. It is also recommended that the outputs remain
disabled until the device completes power-up after asserting nPD.
NOTE 2: The Power Down Timing diagram assumes that GL is HIGH.
NOTE 3: It should be noted that during power-down mode, the outputs are both pulled to VDD. In the Power Down Timing diagram this is
shown when Qx, nQx goes to VDIF = 0.
IDT8R9306NLI REVISION D AUGUST 21, 2013
10
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Test Circuit for Differential Input
~50
VIN
Transmission Line
VDD/2
A
A
D.U.T.
Pulse
Generator
~50
nVIN
Transmission Line
-VDD/2
Scope
50
50
Table 6A. Differential Input Test Conditions
Symbol
VDD = 2.5V 0.2V
Unit
VTHI
Crossing of A and nA
V
IDT8R9306NLI REVISION D AUGUST 21, 2013
11
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Test Circuit for DC Outputs and Power Down Tests
VDD
A
Qn
Pulse
RL
RL
Generator
nA
D.U.T.
VOS
VOD
nQn
Test Circuit for Propagation, Skew, and Gate Enable/Disable Timing
~50
VIN
Transmission Line
VDD/2
A
D.U.T.
Pulse
Generator
A
~50
nVIN
Transmission Line
-VDD/2
Scope
50
50
Table 6B. LVDS Differential Output Test Conditions
Symbol
VDD = 2.5V 0.2V
Unit
pF
pF
0(1)
8(1,2)
50
CL
RL
NOTE 1: Specifications only apply to “Normal Operations” test condition. The TIA/EIA specification load is for reference only.
NOTE 2: The scope inputs are assumed to have a 2pF load to ground. TIA/EIA – 644 specifies 5pF between the output pair.
With CL = 8pF, this gives the test circuit appropriate 5pF equivalent load.
IDT8R9306NLI REVISION D AUGUST 21, 2013
12
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Applications Information
Recommendations for Unused Output Pins
Inputs:
Outputs:
LVCMOS Control Pins
LVDS Outputs
The input controls must not be treated as unused inputs. All control
pins are floating and have no default state. Each must be configured
All unused LVDS output pairs can be either left floating or terminated
with 100across. If they are left floating, we recommend that there
is no trace attached.
by tying a 1kresistor to either ground or VDD
.
Clock Input
For applications not requiring the use of the second input clock
Ax/nAx, it can be left floating. Though not required, but for additional
protection, a 1kresistor can be tied from Ax to ground and a 1k
resistor can be tied from nAx to VDD
.
IDT8R9306NLI REVISION D AUGUST 21, 2013
13
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
VFQFPN EPAD Thermal Release Path
In order to maximize both the removal of heat from the package and
the electrical performance, a land pattern must be incorporated on
the Printed Circuit Board (PCB) within the footprint of the package
corresponding to the exposed metal pad or exposed heat slug on the
package, as shown in Figure 1. The solderable area on the PCB, as
defined by the solder mask, should be at least the same size/shape
as the exposed pad/slug area on the package to maximize the
thermal/electrical performance. Sufficient clearance should be
designed on the PCB between the outer edges of the land pattern
and the inner edges of pad pattern for the leads to avoid any shorts.
and dependent upon the package power dissipation as well as
electrical conductivity requirements. Thus, thermal and electrical
analysis and/or testing are recommended to determine the minimum
number needed. Maximum thermal and electrical performance is
achieved when an array of vias is incorporated in the land pattern. It
is recommended to use as many vias connected to ground as
possible. It is also recommended that the via diameter should be 12
to 13mils (0.30 to 0.33mm) with 1oz copper via barrel plating. This is
desirable to avoid any solder wicking inside the via during the
soldering process which may result in voids in solder between the
exposed pad/slug and the thermal land. Precautions should be taken
to eliminate any solder voids between the exposed heat slug and the
land pattern. Note: These recommendations are to be used as a
guideline only. For further information, please refer to the Application
Note on the Surface Mount Assembly of Amkor’s Thermally/
Electrically Enhance Leadframe Base Package, Amkor Technology.
While the land pattern on the PCB provides a means of heat transfer
and electrical grounding from the package to the board through a
solder joint, thermal vias are necessary to effectively conduct from
the surface of the PCB to the ground plane(s). The land pattern must
be connected to ground through these vias. The vias act as “heat
pipes”. The number of vias (i.e. “heat pipes”) are application specific
SOLDER
SOLDER
PIN
PIN
EXPOSED HEAT SLUG
PIN PAD
GROUND PLANE
LAND PATTERN
(GROUND PAD)
PIN PAD
THERMAL VIA
Figure 1. P.C. Assembly for Exposed Pad Thermal Release Path – Side View (drawing not to scale)
IDT8R9306NLI REVISION D AUGUST 21, 2013
14
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Package Drawing and Dimensions
28 Lead VFQFPN Package Outline and Package Dimensions
IDT8R9306NLI REVISION D AUGUST 21, 2013
15
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Package Drawing and Dimensions, Continued
28 Lead VFQFPN Package Outline and Package Dimensions
IDT8R9306NLI REVISION D AUGUST 21, 2013
16
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Ordering Information
XX
X
XXXXX
IDT
Package Process
Device Type
I
-40 C to +85 C (Industrial)
NL
NLG
Thermall Enhanced Plastic Very Fine Pitch
Quad Flat, “Green” Package
8R9306I 2.5V 1:6 LVDS Clock Buffer Terabuffer II
Table 8. Ordering Information
Part/Order Number
Marking
Package
“Lead-Free” 28 Lead VFQFPN
“Lead-Free” 28 Lead VFQFPN
Shipping Packaging
Tray
Temperature
-40C to 85C
-40C to 85C
8R9306NLGI
8R9306NLGI8
IDT8R9306NLGI
IDT8R9306NLGI
Tape & Reel
IDT8R9306NLI REVISION D AUGUST 21, 2013
17
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
Revision History Sheet
Rev
Table
Page
Description of Change
Date
B
T5F
9
1
Changed fo, Frequency Range Maximum from 1MHz to 1GHz.
4/11/2012
Features, first bullet: changed 25ps to 40ps
Features, eighth bullet: changed two LVDS outputs to six LVDS outputs
Pin Assignment: changed dimensions from 5mm x 5mm to 6mm x 6mm
Pin Assignment: added EPad dimensions
C
4A
5F
5
8
13
15, 16
17
ITOT, Test Conditions: changed FREF Clock from 450MHz to 1GHz
6/26/2013
tsk(o): changed 25ps Max to 40ps Max
Added: Recommendations for Unused Output Pins
Updated Package Drawing
8
Deleted quantity from Tape & Reel
1, 14, 15,
16, 17
D
D
Changed VFQFN to VFQFPN.
7/25/2013
8/16/2013
T1
3
First row: Corrected typo - A[1:2].
Added ‘I’ to Ordering Information diagram.
17
IDT8R9306NLI REVISION D AUGUST 21, 2013
18
©2013 Integrated Device Technology, Inc.
IDT8R9306I Data Sheet
2.5V LVDS 1:6 CLOCK BUFFER TERABUFFER™ II
We’ve Got Your Timing Solution
6024 Silver Creek Valley Road Sales
Technical Support Sales
800-345-7015 (inside USA)
netcom@idt.com
San Jose, California 95138
+408-284-8200 (outside USA) +480-763-2056
Fax: 408-284-2775
www.IDT.com/go/contactIDT
DISCLAIMER Integrated Device Technology, Inc. (IDT) and its subsidiaries reserve the right to modify the products and/or specifications described herein at any time and at IDT’s sole discretion. All information in this document,
including descriptions of product features and performance, is subject to change without notice. Performance specifications and the operating parameters of the described products are determined in the independent state and are not
guaranteed to perform the same way when installed in customer products. The information contained herein is provided without representation or warranty of any kind, whether express or implied, including, but not limited to, the
suitability of IDT’s products for any particular purpose, an implied warranty of merchantability, or non-infringement of the intellectual property rights of others. This document is presented only as a guide and does not convey any
license under intellectual property rights of IDT or any third parties.
IDT’s products are not intended for use in applications involving extreme environmental conditions or in life support systems or similar devices where the failure or malfunction of an IDT product can be reasonably expected to signifi-
cantly affect the health or safety of users. Anyone using an IDT product in such a manner does so at their own risk, absent an express, written agreement by IDT.
Integrated Device Technology, IDT and the IDT logo are registered trademarks of IDT. Other trademarks and service marks used herein, including protected names, logos and designs, are the property of IDT or their respective third
party owners.
Copyright 2013. All rights reserved.
厂商 型号 描述 页数 下载

IDT

 		8R9306NLGI8 [ 2.5V LVDS, 1:6 Clock Buffer Terabuffer ] 19 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.240499s
