1T1G thru 1T7G
Taiwan Semiconductor
CREAT BY ART
Glass Passivated Rectifiers
FEATURES
- Low forward voltage drop
- High current capability
- High reliability
- High surge current capability
- 3mm miniature body
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
MECHANICAL DATA
Case: TS-1
TS-1
Molding compound, UL flammability classification rating 94V-0
Base P/N with suffix "G" on packing code - green compound (halogen-free)
Terminal: Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test
Weight: 0.2g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (TA=25oC unless otherwise noted)
PARAMETER
SYMBOL 1T1G 1T2G 1T3G 1T4G 1T5G 1T6G 1T7G UNIT
Maximum repetitive peak reverse voltage
Maximum RMS voltage
VRRM
VRMS
VDC
50
35
50
100
70
200
140
200
400
280
400
1
600
420
600
800
560
800
1000
700
V
V
V
A
Maximum DC blocking voltage
100
1000
Maximum average forward rectified current
IF(AV)
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
IFSM
VF
IR
30
A
V
Maximum instantaneous forward voltage (Note 1)
@ 1 A
Maximum reverse current @ rated VR TJ=25 oC
TJ=125 oC
1.1
1.0
5
100
μA
Typical junction capacitance (Note 2)
Typical thermal resistance
10
Cj
RθJA
TJ
pF
OC/W
OC
100
Operating junction temperature range
Storage temperature range
- 55 to +150
- 55 to +150
OC
TSTG
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Measured at 1.0 MHz and Applied VR=4.0 Volts
Document Number: DS_D1407004
Version: E14
