8S2TH02FP thru 8S2TH06FP
Pb
8S2TH02FP thru 8S2TH06FP
Pb Free Plating Product
8.0 Ampere Full Pak Insulated Tandem Ultra Fast Recovery Rectifier
Unit: mm
ITO-220AC/TO-220FP-2L
Features
.189(4.8)
¬ Fast switching for high efficiency
¬ Low forward voltage drop
¬ High current capability
¬ Low reverse leakage current
¬ High surge current capability
.406(10.3)
.165(4.2)
.381(9.7)
.134(3.4)
.118(3.0)
.130(3.3)
.114(2.9)
.114(2.9)
.098(2.5)
Mechanical Data
.071(1.8)
.055(1.4)
¬ Case: ITO-220AC(Insulated)
¬ Epoxy: UL 94V-0 rate flame retardant
¬ Terminals: Solderable per MIL-STD-202
method 208
.055(1.4)
.039(1.0)
.035(0.9)
.011(0.3)
.032(.8)
MAX
.1
(2.55)
.1
(2.55)
¬ Polarity:As marked on diode body
¬ Mounting position: Any
¬ Weight: 2.1 gram approximately
Case
Reverse Doubler
Tandem Polarity
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
o
Rating at 25
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
UNIT
SYMBOL
8S2TH02FP 8S2TH04FP 8S2TH06FP
V
V
V
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
VRRM
VRMS
VDC
200
140
200
400
280
400
600
420
600
Maximum DC Blocking Voltage
Maximum Average Forward Rectified
Current TC=100oC
8.0
100
1.3
A
A
V
IF(AV)
Peak Forward Surge Current, 8.3ms single
Half sine-wave superimposed on rated load
(JEDEC method)
IFSM
Maximum Instantaneous Forward Voltage
@ 5.0 A
1.7
VF
IR
0.98
Maximum DC Reverse Current @TJ=25oC
At Rated DC Blocking Voltage @TJ=125oC
uA
uA
nS
10.0
250
Maximum Reverse Recovery Time (Note 1)
Typical junction Capacitance (Note 2)
Typical Thermal Resistance (Note 3)
Trr
CJ
35
65
pF
o
R JC
2.2
CW
Operating Junction and Storage
Temperature Range
o
C
-55 to +150
TJ, TSTG
NOTES : (1) Reverse recovery test conditions IF = 0.5A, IR = 1.0A, Irr = 0.25A.
(2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts DC.
(3) Thermal Resistance junction to case.
Page 1/2
http://www.thinkisemi.com/
Rev.04
