1 of 1
Creation Date : February 11, 2019 (GMT)
AC-DC Power Supplies
RWS1000B-15/RNew
Product
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Option
Remote ON/OFF control
Please refer to here.
Option Lineup
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
85 to 265V
120 to 340V
85% Typ.
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
15V
12.8 to 17.2V
67A
1005W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
127mm Nom.
63mm Nom.
198mm Nom.
2000g Typ.
Other
Operating Temp. Range
Cooling
-20 to 60°C
Blower fan cooling
UL60950-1
Safety Standard(Certified)
CSA C22.2 No.60950-1
EN60950-1
Safety Standard(Conformed)
Remarks
Den-an Appendix 12
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
! Images are for reference only and show exemplary products.
! This PDF document was created based on the data listed on the TDK Corporation website.
! All specifications are subject to change without notice.
Copyright(c) TDK Corporation. All rights reserved.
