Creation Date : January 31, 2019 (GMT)
AC-DC Power Supplies
RWS600B-24/R
Sales Region
Series
Worldwide
RWS-B
Status
Production
Feature
Option
Remote ON/OFF control
Please refer to here.
Option Lineup
Recommended EMC Filter Please refer to here.
Accessories
Please refer to the catalog
Electrical Characteristics
Input Voltage Range[AC]
Input Voltage Range[DC]
Efficiency
85 to 265V
120 to 330V
88.5% Typ.
24V
Rated Output Voltage[DC]
Output Voltage Range[DC]
Maximum Output Current
Maximum Output Power
21.6 to 27.6V
25A
600W
Cases Shape & Size
Unit
Case’ shape
Width(W)
Height(H)
Depth(D)
Weight
61mm Nom.
120mm Nom.
190mm Nom.
1600g Typ.
Other
Operating Temp. Range
Cooling
-20 to 70°C
Blower fan cooling
UL60950-1
CSA C22.2 No.60950-1
CSA C22.2 No.107.1-01
EN60950-1
Safety Standard(Certified)
UL508
Safety Standard(Conformed)
Remarks
Den-an Appendix 8 at 100VAC only
This page only shows representative characteristics. Please refer to the
technical data for detailed specifications and conditions.
