RWST50373AR470JBO1

型号:

RWST50373AR470JBO1

品牌:

VISHAY[ VISHAY ]

页数:

5 页

PDF大小:

147 K

RWST
Vishay Sfernice
Fixed Wirewound High Power Vitreous Resistors
Electrical Traction Model
FEATURES
95 W to 800 W at 25 °C
NF C 93-214
RB 25 x 168, RB 30 x 250
Rugged construction for use in severe environmental
conditions
Compliant to RoHS directive 2002/95/EC
“CS” Type 1 Collars
The RWST vitreous wirewound high power resistors are known for their excellent reliability which has developed out of the
VISHAY SFERNICE experience over several decades in the field of high current applications.
Extremely severe conditions of use are encountered in electrical traction including repeated overloads. To withstand such
conditions the new RWST model is extremely rugged and is manufactured to a very carefully monitored process using the best
materials.
NF F 16101, 10/1988 and 16102, 04/1992: Not applicable (our parts are made of metallic and refractory materials).
NF C 93-214. Performances according to NF C 93-214.
DIMENSIONS in millimeters
STAINLESS STEEL 304 L COLLARS “CS” TYPE 1
STAINLESS STEEL 304 L COLLARS “CS” TYPE 2
A
Ø C
A
23
D
D
E
E
3
Ø B
Ø B
58
26
F
F
G
H
15
J
G
H
15
J
WELDED STAINLESS STEEL 304 L COLLARS “AN”
N
WELDED STAINLESS STEEL 304 L BAND “B”
Ø U
Q
Ø B
R
Ø B
Ø C
V
K
P
T
Ø C
Z
S
A
L
A
www.vishay.com
61
For technical questions, contact: sfer@vishay.com
Document Number: 50017
Revision: 12-May-09
RWST
Fixed Wirewound High Power Vitreous Resistors
Electrical Traction Model
Vishay Sfernice
DIMENSIONS in millimeters
RWST STYLE
25 x 138
25 x 168
30 x 250
40 x 370
50 x 373
AN-B
CS type 1
AN-B
CS type 1
AN-B
CS type 1
AN
CS type 2
AN
CS type 2
Connections
A
2
138
28
168
28
250
33
370
45
373
53
Ø B max.
Ø C min.
12
12
17
22
27.1
80 max.
51 1.5
30
D
E
50 1.5
50 1.5
60 1.5
69 max.
45 1.5
30
27
24
1
27
24
1
30
25
1
F
0.5
G - 4/+ 0
H - 4/+ 0
199
169
6.5
229
199
6.5
317
287
9
432
432
405
405
J
0.5
9
9
K
28.5
1
28.5
1
31
13
227
1
45 1.5
18
51 1.5
18
L - 0/+ 0.5
N
9
9
117
2
147
2
2
332
3
332
3
P
51 1.5
15
51 1.5
15
55 1.5
18
81.5 max.
92.5 max.
Q - 0/+ 0.5
R - 0.3/+ 0.9
S max.
-
-
26
26
31
-
-
38.5
23.5
5.7
38.5
23.5
5.7
43.5
26
-
-
-
T
1
-
9.2
Ø U
V
5.7
9.2
33.5
1
33.5
1
36
1
57 1.5
10
63 1.5
11.5
Z
6
6
5
Average unit
weight in g
(CS collars)
225
250
445
1400
2200
MECHANICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
Mechanical Protection
Resistive Element
Connections
Vitreous enamel
Ni-Cr wire
2.7 Ω to 430 kΩ
E12-E24 preferred series values)
Resistance Range
CS supporting collars
on Request
Resistance Tolerance
Standard
AN Collar or B
5 ꢀ
Average Unit Weight
225 g to 2200 g
Power Rating
95 W to 800 W at 25 °C
75 ppm/°C (typical)
0.1 ꢀ year (typical)
ENVIRONMENTAL SPECIFICATIONS
Temperature Coefficient
Shelf Life
Temperature Limits
Climatic Category
- 55 °C + 450 °C
- 55 °C/+ 200 °C/56 days
PERFORMANCE
TYPICAL VALUES AND
DRIFTS
TESTS
CONDITIONS
REQUIREMENTS
10 Pr during 5 s
Voltage limited at < 5000 V
Short Time Overload
Climatic Sequence
2 ꢀ or 0.05 Ω
2 ꢀ or 0.05 Ω
0.5 ꢀ
0.5 ꢀ
- 55 °C + 200 °C
Insulation resistance 100 MΩ
Humidity
56 days
95 ꢀ relative humidity
3 ꢀ or 0.05 Ω
0.5 ꢀ
0.5 ꢀ
(Steady State)
Insulation resistance 100 MΩ
Load at 100 ꢀ Pr followed by cold
temperature exposure at - 55 °C/15'
Thermal Shock
Shock
2 ꢀ or 0.05 Ω
Severity 50 A
9 shocks/each side
1 ꢀ or 0.05 Ω
1 ꢀ or 0.05 Ω
1 ꢀ or 0.05 Ω
0.25 ꢀ
0.25 ꢀ
0.5 ꢀ
Vibration
Severity 55B
Terminal Strength
AN
B
Traction 40 Ncm
Torque 60 Ncm
1000 h
5000 h
1 ꢀ
2 ꢀ
90'/30' cycle
1000 h at Pr 25 °C
Load Life
5 ꢀ
Document Number: 50017
Revision: 12-May-09
For technical questions, contact: sfer@vishay.com
www.vishay.com
62
RWST
Fixed Wirewound High Power Vitreous Resistors
Electrical Traction Model
Vishay Sfernice
SPECIAL FEATURES
RWST STYLE
25 x 138
25 x 168
RB 25 x 168
160 W
30 x 250
RB 30 x 250
280 W
40 x 370
-
50 x 373
-
Designation NF C 93-214
Power Rating at 25 °C
Maximum Power
-
95 W
500 W
700 W
110 W
180 W
320 W
600 W
800 W
Rating at 25 °C
P max.
Ohmic Range
(E12, E24 series)
2.7 Ω
82 kΩ
2.7 Ω
100 kΩ 4.7 Ω
220 kΩ 8.2 Ω
360 kΩ 12 Ω
430 kΩ
Limiting Element Voltage
Critical Resistance
1400 V
1900 V
3000 V
4500 V
5000 V
18 kΩ
20 kΩ
30 kΩ
36 kΩ
30 kΩ
NON INDUCTIVE WINDING
For high frequencies, low self induction resistors are available with special windings.
RWSTNI designation.
MODEL AND
STYLE
RWSTNI
25 x 138
RWSTNI
25 x 168
RWSTNI
30 x 250
RWSTNI
40 x 370
RWSTNI
50 x 373
OHMIC RANGE
(E12 SERIES)
22 Ω
2.5 kΩ
22 Ω
4 kΩ
120 Ω
6.8 kΩ
120 Ω
8.2 kΩ
150 Ω
8.2 kΩ
POWER RATING CHART
100
75
50
25
0
0
65
130
195
260
325
390
455
AMBIENT TEMPERATURE IN °C
TEMPERATURE RISE
400
300
RWST 25
×
138
200
100
0
10
100
1000
RATED POWER IN W
www.vishay.com
63
For technical questions, contact: sfer@vishay.com
Document Number: 50017
Revision: 12-May-09
RWST
Fixed Wirewound High Power Vitreous Resistors
Electrical Traction Model
Vishay Sfernice
MARKING
PACKAGING
Box: Fixed quantity depending on size and connections.
SFERNICE trademark, model, style, nominal resistance
(in Ω), tolerance (in ꢀ), manufacturing date.
ORDERING INFORMATION
RWST
25 × 138
B
56U
5 %
B06
e
MODEL
STYLE NON-INDUCTIVE SPECIAL CONNECTIONS
OHMIC VALUE
TOLERANCE PACKAGING
LEAD
(Pb)-FREE
WINDING
Optional
DESIGN
Optional
Custom items are
subject to extra-charge
and min. order.
Please see price list.
GLOBAL PART NUMBER INFORMATION
R
W
S
T
2
5
1
6
8
C
4
7
0
0
J
B
0
4
GLOBAL
MODEL
PACKAGING
SPECIAL
SIZE
LEADS
OPTION
OHMIC VALUE
TOLERANCE
RWST
25138
25168
30250
40370
50373
A = AN
B = B
C = CS
N = Non
inductive
winding
J = 5.0 ꢀ
K = 10 ꢀ
Box:
BO1
BO2
BO2NA
BO4
BO4NA
BO6
As applicable.
Example: BA7
The first three digits are
significant figures and
the last digit specifies
the number of zeros to
F = Faston
follow.
R
designates
decimal point.
4700 = 470 Ω
48R8 = 48.7 Ω
R010 = 0.01 Ω
R470 = 0.47 Ω
BO6NA
Document Number: 50017
Revision: 12-May-09
For technical questions, contact: sfer@vishay.com
www.vishay.com
64
