Part Number: XZFCBD14C
SURFACE MOUNT DISPLAY
Features
Package Schematics
● 0.56 inch digit height
● Robust package
● Low power consumption
● Standard configuration: Gray face w/ white
segments
● Standard Package: 400pcs/ Reel
● MSL (Moisture Sensitivity Level): 2a
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
Notes:
1. All dimensions are in millimeters (inches), Tolerance is ±0.25(0.01")unless otherwise noted.
2. Specifications are subject to change without notice.
3.The gap between the reflector and PCB shall not exceed 0.25mm.
SENSITIVE
DEVICES
Absolute Maximum Ratings
(TA=25°C)
Blue
(InGaN)
Operating Characteristics
(TA=25°C)
Blue
(InGaN)
Unit
Unit
Reverse Voltage
Forward Current
VR
IF
5
V
Forward Voltage (Typ.) (IF=10mA)
Forward Voltage (Max.) (IF=10mA)
Reverse Current (Max.) (VR=5V)
VF
VF
IR
3
V
V
30
mA
3.5
50
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
μA
iFS
150
mA
Wavelength of Peak
Emission CIE127-2007* (Typ.)
(IF=10mA)
λP
λD
460*
465*
nm
nm
Power Dissipation
PD
TA
120
mW
°C
Operating Temperature
Storage Temperature
-40 ~ +85
-40 ~ +85
Wavelength of Dominant
Emission CIE127-2007* (Typ.)
(IF=10mA)
Tstg
Electrostatic Discharge Threshold
(HBM)
Spectral Line Full Width
At Half-Maximum (Typ.)
(IF=10mA)
250
V
△λ
25
nm
pF
A Relative Humidity between 40% and 60% is recommended in
ESD-protected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625-A and JEDEC/J-STD-033)
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
100
Luminous Intensity Wavelength
Part
Number
Emitting
Color
Emitting
Material
CIE127-2007*
(IF=10mA)
ucd
CIE127-2007*
Description
nm
λP
min.
typ.
Common Cathode, Rt.
Hand Decimal.
XZFCBD14C
Blue
InGaN
5600*
14990*
460*
*Luminous intensity value and wavelength are in accordance with CIE127-2007 standards.
Mar 26,2019
XDSB5543 V5-Z Layout: Maggie L.
