Part Number: XZVG50W-2
3.0x2.0mm RIGHT ANGLE SMD LED
Features
Package Schematics
● Ideal for indication light on hand held products
● Long life and robust package
● Standard Package: 2,000pcs/ Reel
● MSL (Moisture Sensitivity Level): 3
● RoHS compliant
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.2(0.008") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(TA=25°C)
Green
(AlGaInP)
Operating Characteristics
(TA=25°C)
Green
(AlGaInP)
Unit
Unit
V
Reverse Voltage
Forward Current
VR
IF
5
V
Forward Voltage (Typ.)
(IF=20mA)
VF
VF
IR
2.1
2.5
10
30
mA
Forward Voltage (Max.)
(IF=20mA)
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
V
iFS
150
mA
Reverse Current (Max.)
(VR=5V)
uA
Power Dissipation
PD
TA
75
mW
°C
Wavelength of Peak
Emission CIE127-2007* (Typ.)
(IF=20mA)
Operating Temperature
Storage Temperature
-40 ~ +85
-40 ~ +85
λP
λD
574*
570*
nm
nm
Tstg
A Relative Humidity between 40% and 60% is recommended in
ESD-protected work areas to reduce static build up during assembly
process (Reference JEDEC/JESD625-A and JEDEC/J-STD-033)
Wavelength of Dominant
Emission CIE127-2007* (Typ.)
(IF=20mA)
Spectral Line Full Width
At Half-Maximum (Typ.)
(IF=20mA)
△λ
20
15
nm
pF
Capacitance (Typ.)
(VF=0V, f=1MHz)
C
Luminous Intensity
Wavelength
CIE127-2007*
Viewing
Angle
2θ 1/2
Part
Number
Emitting
Color
Emitting
Material
CIE127-2007*
(IF=20mA)
mcd
Lens-color
nm
λP
min.
200*
typ.
XZVG50W-2
Green
AlGaInP
Water Clear
397*
574*
10°
*Luminous intensity value and wavelength are in accordance with CIE127-2007 standards.
Sep 22,2016
XDSB0292 V7-Z Layout: Maggie L.
P. 1/4
