Vishay intertechnology, inc.
ceramic Disc capacitors
VY2ꢀSeries
AC Line Rated Disc Capacitors
Class X1, 440 VAC, Class Y2, 300 VAC
DIMENSIONS
DR = 3.0 mm
max.
F
SH = 4.0 mm
max.
Ø d 0.6 mm
T
D
L = 30.0 mm
5.0 mm
Capacitors with 5.0 mm, 7.5 mm and 10 mm lead spacing
ORDERING INFORMATION
CLEAR TEXT CODE
BODY
BODY
LEAD
COATING
15TH DIGIT:
FEATURES
TOL.
TEMP.
DIAMETER THICKNESS SPACING EXTENSION
C (pF)
T = REEL; U = AMMO; 3 = BULK (1)
• Complying with IEC 60384-14, 3rd edition
• High reliability
(2)
(%) COEFFICIENT
DMAX.
(mm)
TMAX.
(mm)
F
DRMAX.
(mm)
RoHS AND
HALOGEN-FREE
(mm)
RoHS COMPLIANT
• Vertical (inline) kinked or straight leads
VY2 for leadspacing 5.0 mm
10
15
2200 VAC, 50 Hz, 2 s
VY2100K29U2JS6*V5
VY2150K29U2JS6*V5
VY2220K29U2JS6*V5
VY2330K29U2JS6*V5
VY2470K29U2JS6*V5
VY2100K29U2JG6*V5
VY2150K29U2JG6*V5
VY2220K29U2JG6*V5
VY2330K29U2JG6*V5
VY2470K29U2JG6*V5
• Material categorization:
For definitions of compliance please see
www.vishay.com/doc?99912
22
U2J (N750)
33
47
APPLICATIONS
• Across-the-line
• Line by-pass
68
10
20
VY2680K29Y5SS6*V5 VY2680K29Y5SG6*V5
VY2101K29Y5SS6*V5 VY2101K29Y5SG6*V5
VY2151K29Y5SS6*V5 VY2151K29Y5SG6*V5
VY2221K29Y5SS6*V5 VY2221K29Y5SG6*V5
VY2331K29Y5SS6*V5 VY2331K29Y5SG6*V5
VY2471K29Y5SS6*V5 VY2471K29Y5SG6*V5
VY2681M29Y5US6*V5 VY2681M29Y5UG6*V5
VY2102M29Y5US6*V5 VY2102M29Y5UG6*V5
VY2152M31Y5US6*V5 VY2152M31Y5UG6*V5
VY2222M35Y5US6*V5 VY2222M35Y5UG6*V5
VY2332M41Y5US6*V5 VY2332M41Y5UG6*V5
VY2392M43Y5US6*V5 VY2392M43Y5UG6*V5
100
150
220
330
470
680
1000
1500
2200
3300
3900
7.5
Y5S (2C3)
5.0
5.0
3.0
• Antenna coupling
DESIGN
The capacitors consist of a ceramic disc both sides of which
are silver-plated. Connection leads are made of tinned
copper having a diameter of 0.6 mm.
The capacitors may be supplied with vertical (inline) kinked
leads having a lead spacing of 5.0 mm, 7.5 mm, or 10.0 mm.
Encapsulation is made of flammable resistant epoxy resin in
accordance with “UL 94 V-0”
8.0
9.0
10.5
11.0
Y5U (2E3)
ORDERING INFORMATION
CLEAR TEXT CODE
15TH DIGIT:
CAPACITANCE RANGE
10 pF to 0.01 μF
BODY
BODY
LEAD
COATING
TOL.
TEMP.
DIAMETER THICKNESS SPACING EXTENSION
C (pF)
T = REEL; U = AMMO; 3 = BULK (1)
(2)
(%) COEFFICIENT
DMAX.
(mm)
TMAX.
(mm)
F
DRMAX.
(mm)
RoHS AND
HALOGEN-FREE
(mm)
RoHS COMPLIANT
RATED VOLTAGE UR
IEC 60384-14 and UL60384-14:
(X1): 440 VAC, 50 Hz
VY2 for leadspacing 7.5 mm
2600 VAC, 50 Hz, 2 s
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
3900
4700
6800
0.01 μF
VY2100K29U2JS6*V7
VY2150K29U2JS6*V7
VY2220K29U2JS6*V7
VY2330K29U2JS6*V7
VY2470K29U2JS6*V7
VY2100K29U2JG6*V7
VY2150K29U2JG6*V7
VY2220K29U2JG6*V7
VY2330K29U2JG6*V7
VY2470K29U2JG6*V7
(Y2): 300 VAC, 50 Hz
10
U2J (N750)
TEST VOLTAGE
Component test (100 %)
2600 VAC, 50 Hz, 2 s
(2600 VAC for LS 7.5 mm and 10 mm)
(2200 VAC for LS 5.0 mm)
Random sampling test (destructive test)
2600 VAC, 50 Hz, 60 s
Voltage proof of coating (destructive test)
2600 VAC, 50 Hz, 60 s
VY2680K29Y5SS6*V7 VY2680K29Y5SG6*V7
VY2101K29Y5SS6*V7 VY2101K29Y5SG6*V7
VY2151K29Y5SS6*V7 VY2151K29Y5SG6*V7
VY2221K29Y5SS6*V7 VY2221K29Y5SG6*V7
VY2331K29Y5SS6*V7 VY2331K29Y5SG6*V7
VY2471K29Y5SS6*V7 VY2471K29Y5SG6*V7
VY2681M29Y5US6*V7 VY2681M29Y5UG6*V7
VY2102M29Y5US6*V7 VY2102M29Y5UG6*V7
VY2152M31Y5US6*V7 VY2152M31Y5UG6*V7
VY2222M35Y5US6*V7 VY2222M35Y5UG6*V7
VY2332M41Y5US6*V7 VY2332M41Y5UG6*V7
VY2392M43Y5US6*V7 VY2392M43Y5UG6*V7
VY2472M49Y5US6*V7 VY2472M49Y5UG6*V7
VY2682M59Y5US63V7 VY2682M59Y5UG63V7
VY2103M63Y5US63V7 VY2103M63Y5UG63V7
7.5
10
Y5S (2C3)
5.0
7.5
3.0
8.0
9.0
20
Y5U (2E3)
10.5
11.0
12.5
14.5
16.0
INSULATION RESISTANCE
10 000 M minimum
TOLERANCE OF CAPACITANCE
± 20 % (code M); ± 10 % (code K)
QUICK REFERENCE DATA
DISSIPATION FACTOR
CLASS CLASS CLASS CLASS CLASS CLASS
X1 X1 X1 Y2 Y2 Y2
(U2J) (Y5S) (Y5U) (U2J) (Y5S) (Y5U)
2.5 % maximum
The capacitors meet the essential requirements of
“EIA 198”. Unless stated otherwise all electrical values apply
at an ambient temperature of 25 °C
atmospheric conditions
DESCRIPTION
Voltage (VAC
)
440
300
3 °C, at normal
Min.
Capacitance
(pF)
10
47
68
680
10
47
68
680
OPERATING TEMPERATURE RANGE
- 40 °C to + 125 °C
Max.
Capacitance
(pF)
680 10 000
680 10 000
TEMPERATURE CHARACTERISTICS
Mounting
Through hole
See Ordering Information Tables
CLIMATIC CATEGORY
40/125/21 according to EN 60068-1
COATING
According to UL 94 V-0
Epoxy resin, isolating, flame retardant
APPROVALS
ENEC - VDE DE 1-30691
UL60384-14 file E183844
CSA 22.2
PACKAGING
Bulk; tape and reel; taped ammopack
PRODUCT SHEET
2/2
VMN-PT9159-1306
