TVS Diodes
Surface Mount > 500W > SZNS6A5.0FT3G
OBSOLETE/EOL
Pb
SZNS6A5.0AFT3G Series
DATE Dec/31/2017,
REPLACED BY TPSMA6LSeries
Description
The SZNS6AxxAFT3G series is designed to protect voltage
sensitive components from high voltage, high energy
transients. This device has excellent clamping capability,
high surge capability, low zener impedance and fast
response time. The SZNS6AxxAFT3G series is ideally
suited for use in computer hard disk drives, communication
systems, automotive, numerical controls, process controls,
medical equipment, business machines, power supplies
and many other industrial/consumer applications.
Features
• Peak Reverse Working Voltage Range − 5 V to 64 V
• Peak Pulse Power of 500 W (10 x 1000 sec)
• ESD Rating of Class 3 (>16 kV) per Human Body Model
• ESD Rating of Class 4 (>8 kV) IEC 61000−4−2
• Fast ResponseTime
Maximum Ratings andThermal Characteristics
Rating
Symbol
PPK
Value
500
Unit
W
Peak Power Dissipation (Note 1) @TL =
25°C, Pulse Width = 1 ms
• Low Profile Package
DC Power Dissipation (Note 3)
@TA = 75°C
• These Devices are Pb−Free and are RoHS Compliant
1.5
20
50
W
PD
• SZ Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements;
AEC−Q101 Qualified and PPAP Capable
Derate Above 75°C
mW/°C
°C/W
R
Thermal Resistance from Junction−to−
Ambient
8JL
W
DC Power Dissipation (Note 3) @TA =
25°C Derate Above 25°C
0.5
4.0
250
PD
Functional Diagram
mW/°C
°C/W
R
Thermal Resistance from Junction−to−
Ambient
8JA
Cathode
Anode
Forward Surge Current (Note 4) @TA =
25°C
IFSM
40
A
Additional Information
Operating and StorageTemperature
Range
−65 to
+150
TJ, Tstg
°C
Notes:
Samples
Datasheet
Resources
1. 10 X 1000 µs, non−repetitive.
2. 1 in square copper pad, FR−4 board.
3. FR−4 board, using Littelfuse minimum recommended footprint, as shown in 403AA case
outline dimensions spec.
4. 1/2 sine wave (or equivalent square wave), PW = 8.3 ms, duty cycle = 4 pulses per minute
maximum
© 2017 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/03/17
