Part Number:
Status:
1200705210
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 8 Poles, PG9 Mounting Threads, PCB Pins
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Industrial Receptacles
120070
Series image - Reference only
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
EU ELV
Not Relevant
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
PCB Mount
EU RoHS
China RoHS
Compliant with
Exemption 6(c)
REACH SVHC
Contained Per -
ED/88/2018 (15
January 2019)
Lead
UPC
884982224773
Physical
Coupling Type
Gender
Keyway
Length
Internal Thread
Female
Single
N/A
Halogen-Free
Status
Low-Halogen
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
Nickel-plated Brass
PG9
16.236/g
Straight
Back
For more information, please visit Contact US
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
8
-20°C to +80°C
N/A
N/A
Electrical
Current - Maximum per Contact
Voltage - Maximum
Search Parts in this Series
120070 Series
4.0A
30V AC / 36V DC
Material Info
Engineering Number
8R8J400013
Reference - Drawing Numbers
Sales Drawing
SD-120070-013
