Magnetic cylinder sensors
Magnetic cylinder sensors
MZTK 06P1011/KS35D
dimension drawing
6,2
4,3
LED
sensing face
5
M8 x 1
general data
type
magneto-resistive
T-slots
version
nominal operation point
difference ON-OFF
output indicator
4 mT
0,5 ... 1,5 mT
LED yellow
electrical data
switching frequency
response time / release time
output circuit
< 200 kHz
< 0,0025 ms
PNP
current consumption max. (no load)
output current
12 mA
< 200 mA
5 ... 30 VDC
normally open (NO)
< 1 VDC
yes
voltage supply range +Vs
output function
connection diagram
voltage drop Vd
reverse polarity protection
short circuit protection
BN (1)
+VS
yes
BK (4)
output
0 V
PNP
Z
mechanical data
cable output
connection types
type
BU (3)
axial
flylead connector PUR M8, L=300 mm
rectangular
31 mm
6,2 mm
4,3 mm
PA66
depth
width / diameter
height / length
housing material
ꢀ Oil- and salt water climate resistant
ambient conditions
operating temperature
protection class
-10 ... +70 °C
IP 67
