This document was generated on 04/02/2019
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
1200110035
EU ELV
Not Relevant
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 5 Poles, M12x1 and M14x1 Threads, Male (Straight)
to Leads, 0.30m (11.81") Length
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Contained Per -
ED/108/2014 (17 Dec
2014)
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Halogen-Free
Status
Not Low-Halogen
General
Product Family
Series
IP Rating
NEMA Rating
Overview
Product Name
Type
Industrial Receptacles
120011
IP67
For more information, please visit Contact US
NEMA 6
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
883906175535
UPC
Physical
Coupling Type
Gender
Search Parts in this Series
120011 Series
External Thread
Male
Keyway
Single
Length
0.30m
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
Nickel-plated Brass
M14 x 1.0
22.070/g
Straight
Front
5
Temperature Range - Operating
Wire Size AWG
-20°C to +80°C
22
Wire/Cable Type
Leads, UL 1061
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R5E36E03C3003
SD-120070-236
Reference - Drawing Numbers
Sales Drawing
