Part Number:
Status:
1200700235
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 5 Poles, M16x1.5 Mounting Threads, PCB Pin
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Industrial Receptacles
120070
Series image - Reference only
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
EU ELV
Not Relevant
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
PCB Mount
EU RoHS
China RoHS
Compliant with
Exemption 6(c)
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
UPC
191128078450
Physical
Coupling Type
Gender
Keyway
Length
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
External Thread
Male
Single
N/A
Nickel-plated Brass
PG9
18.000/g
Straight
Back
Low-Halogen
For more information, please visit Contact US
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
5
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-20°C to +80°C
N/A
N/A
Search Parts in this Series
120070 Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R5J460003
Reference - Drawing Numbers
Sales Drawing
SD-120011-281
