ALUMINUM ELECTROLYTIC CAPACITORS
Chip Type, Low Impedance
UWG
Chip type, operating over wide temperature range of to –55 to +105°C
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine fed with carrier tape.
Compliant to the RoHS directive (2011/65/EU).
.
Low
Impedance
Low
Impedance
UUD
UWF
UWG
Specifications
Item
Performance Characteristics
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
–55 to +105°C
6.3 to 50V
1 to 1500µF
20% at 120Hz, 20°C
After 2 minutes' application of rated voltage at 20°C, leakage current is not more than 0.01CV or 3 (µA) , whichever is greater.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
6.3
10
16
25
35
50
Tangent of loss angle (tan δ)
tan δ (MAX.)
0.26
0.19
0.16
0.14
0.12
0.12
Measurement frequency : 120Hz
Rated voltage (V)
Z–25°C / Z+20°C
Z–55°C / Z+20°C
6.3
2
4
10
2
4
16
2
3
25
2
3
50
2
3
35
2
3
Stability at Low Temperature
Impedance ratio
ZT / Z20 (MAX.)
The specifications listed at right shall be met
when the capacitors are restored to 20°C
after the rated voltage is applied for 1000
hours at 105°C.
After storing the capacitors under no load at 105°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the
Capacitance change
tan δ
Leakage current
Within 20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Endurance
Shelf Life
characteristics listed above.
endurance
The capacitors are kept on a hot plate for 30 seconds, which is
maintained at 250°C. The capacitors shall meet the characteristic
requirements listed at right when they are removed from the plate
and restored to 20°C.
Within 10% of the initial capacitance value
Less than or equal to the initial specified value
Less than or equal to the initial specified value
Capacitance change
tan δ
Resistance to soldering
heat
Leakage current
Marking
Black print on the case top.
Chip Type
Type numbering system (Example : 10V 100 F)
µ
1
2
3
4
5
6
7
8
9 10 11 12 13 14
(φ4 to φ6.3)
Positive
U W G 1 A 1 0 1 M C L 1 G S
Plastic platform
0.3 MAX.
Capacitance
Voltage
C
0.2
Taping code
φD code
105˚C Marking
4 to 6.3 GB
•
8
10 GS
Configuration
+0.1
H
L
-0.2
φD
4 to 6.3
8 (6.2L)
•
code
CL
CL
Lot No.
Negative
Capacitance tolerance ( 20ꢀ)
Rated capacitance (100µF)
Rated voltage (10V)
Series name
(φ8 × 6.2 )
Capacitance
Positive
8 (10L) 10 NL
Plastic platform
0.3 MAX.
105˚C Marking
Voltage
Trade mark
C
0.2
Type
H
L
0.3
Lot No.
Negative
(mm)
φD × L
×
×
×
×
×
×
4
5.4
5
5.4
6.3 5.4
8
6.2
8
10
10 10
(φ8 × 10, φ10 × 10 )
Capacitance
Positive
A
B
C
E
L
1.8
4.3
4.3
1.0
5.4
2.1
5.3
5.3
1.3
5.4
2.4
6.6
6.6
2.2
5.4
3.3
8.3
8.3
2.3
6.2
2.9
8.3
8.3
3.1
10
3.2
10.3
10.3
4.5
Plastic platform
0.3 MAX.
105˚C Marking
Voltage
Trade mark
C
0.2
10
H
0.5 to 0.8 0.5 to 0.8 0.5 to 0.8 0.5 to 0.8 0.8 to 1.1 0.8 to 1.1
H
L
0.5
Lot No.
Voltage mark for 6.3V is 6V
Negative
Pressure relief vent
.
Dimension table in next page.
