VTO 39
IdAV = 39 A
VRRM = 600-1200 V
Three Phase Rectifier Bridge
Priliminary data
F
VRSM
VDSM
VRRM
VDRM
Type
L
I
N
B
M
J
H
V
V
700
900
1300
600
800
1200
VTO 39-06io7
VTO 39-08io7
VTO 39-12io7
E
G
A
Features
Symbol
Test Conditions
Maximum Ratings
IdAV
ITAVM
①
TC = 85°C, module
TC = 85°C; (180° sine ; per thyristor)
39
16
A
A
• Package with DCB ceramic
base plate
ITSM
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
200
210
A
A
• Isolation voltage 3000 V~
• Planar passivated chips
• Low forward voltage drop
• Leads suitable for PC board soldering
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
180
190
A
A
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
200
150
A2s
A2s
Applications
• Supplies for DC power equipment
• Input rectifiers for PWM inverter
• Battery DC power supplies
T
VJ = TVJM
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
160
150
A2s
A2s
VR = 0
(di/dt)cr
TVJ = TVJM
repetitive, IT = 20 A
100
A/ms
• Field supply for DC motors
f =50 Hz, tP =200 ms
VD = 2/3 VDRM
IG = 0.15 A
Advantages
non repetitive, IT = ITAVM
VDR = 2/3 VDRM
500
500
10
A/ms
V/ms
V
diG/dt = 0.15 A/ms
• Easy to mount with two screws
• Space and weight savings
• Improved temperature and power
cycling capability
(dv/dt)cr
TVJ = TVJM
;
RGK = ¥; method 1 (linear voltage rise)
VRGM
PGM
• Small and light weight
TVJ = TVJM
IT = ITAVM
tp = 30 ms
tp = 300 ms
£
£
5
2.5
0.5
W
W
W
PGAVM
TVJ
TVJM
Tstg
-40...+125
125
-40...+125
°C
°C
°C
VISOL
50/60 Hz, RMS
IISOL £ 1 mA
t = 1 min
t = 1 s
2500
3000
V~
V~
Md
Mounting torque (M4)
1.5 - 2
Nm
14 - 18 lb.in.
18
Weight
typ.
g
Data according to IEC 60747 refer to a single diode/thyristor unless otherwise stated
① for resistive load at bridge output. IXYS reserves the right to change limits, test conditions and dimensions.
© 2000 IXYS All rights reserved
1 - 2
