3.3V SDRAM Modules
HYS64V32220GD(L)-8A
256MB PC100 144 pin SO-DIMM SDRAM Modules
Preliminary information
• 144 Pin Eight Byte Small Outline Dual-In-Line Synchronous DRAM Modules
for PC 100 notebook applications
• Two bank 32M x 64 non-parity module organisation
• Performance:
-8A
PC100
100
Units
MHz
fCK
tAC
Clock frequency (max.)
Clock access time
CAS latency = 3
6
ns
• Single +3.3V(± 0.3V ) power supply
• Programmable CAS Latency, Burst Length and Wrap Sequence
(Sequential & Interleave)
• Auto Refresh (CBR) and Self Refresh
• Decoupling capacitors mounted on substrate
• All inputs, outputs are LVTTL compatible
2
• Serial Presence Detect with E PROM
• Uses 256Mbit SDRAM components in 16M x 16 SDRAM organisation
• 8192 refresh cycles every 64 ms
• Gold contact pad
• This module family is fully compliant with the latest INTEL SO-DIMM layout specification
INFINEON Technologies
1
6.99
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
This INFINEON modules are industry standard 144 pin 8-byte Synchronous DRAM (SDRAM) Small
Outline Dual In-line Memory Modules (SO-DIMM) which are organised as x64 high speed memory
arrays designed for use in non-parity applications. These SO-DIMMs use 256Mbit SDRAMs in
TSOPII packages. Decoupling capacitors are mounted on the board.
2
The DIMMs use optional serial presence detects implemented via a serial E PROM using the two
2
pin I C protocol. The first 128 bytes are utilized by the DIMM manufacturer and the second 128
bytes are available to the end user.
All INFINEON 144-pin SO-DIMMs provide a high performance, flexible 8-byte interface in a 67,5
mm long footprint.
Product Spectrum:
SDRAMs RowAddr.
used
Bank
Select
Column Refresh Period
Addr.
32M x 64
HYS64V32220GD(L)-8A 8 16Mx16
13
BA0, BA1
9
8k
7,8 µs
Note: All partnumbers end with a place code (not shown), designating the die revision. Consult factory for current
revision. Example: HYS64V32220GD-8A-A, indicating Rev.A dies are used for SDRAM components.
Card Dimensions:
Organisation
32M x 64
PCB-Board
L x H x T [mm]
INTEL Rev. 1.0
67.60 x 31.75 x 3.80
Pin Names
A0-A12
BA0,BA1
DQ0 - DQ63
RAS
Address Inputs for 32M x 64 modules
Bank Selects
Data Input/Output
Row Address Strobe
Column Address Strobe
Read / Write Input
Clock Enable
CAS
WE
CKE0
CLK0
Clock Input
DQMB0 - DQMB7
CS0 - CS3
Vcc
Data Mask
Chip Select
Power (+3.3 Volt)
Ground
Vss
SCL
Clock for Presence Detect
Serial Data Out for Presence Detect
No Connection
SDA
N.C.
INFINEON Technologies
2
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
Pin Configuration
Front
Side
Back
Side
Front
Side
Back
Side
PIN #
PIN #
PIN #
PIN #
1
VSS
2
VSS
73
NC
Vss
NC
NC
Vcc
74
CLK1
3
DQ0
DQ1
DQ2
DQ3
VCC
DQ4
DQ5
DQ6
DQ7
Vss
4
DQ32
DQ33
DQ34
DQ35
Vcc
75
76
Vss
5
6
77
78
NC
7
8
79
80
NC
9
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
81
82
Vcc
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
71
83
DQ16
DQ17
DQ18
DQ19
Vss
84
DQ48
DQ49
DQ50
DQ51
Vss
DQ36
DQ37
DQ38
DQ39
Vss
85
86
87
88
89
90
91
92
93
DQ20
DQ21
DQ22
DQ23
Vcc
94
DQ52
DQ53
DQ54
DQ55
Vcc
DQMB0
DQMB1
Vcc
DQMB4
DQMB5
Vcc
95
96
97
98
99
100
102
104
106
108
110
112
114
116
118
120
122
124
126
128
130
132
134
136
138
140
142
144
A0
A3
101
103
105
107
109
111
113
115
117
119
121
123
125
127
129
131
133
135
137
139
141
143
A1
A4
A6
A7
A2
A5
A8
BA0
Vss
Vss
Vss
Vss
DQ8
DQ9
DQ10
DQ11
Vcc
DQ40
DQ41
DQ42
DQ43
Vcc
A9
BA1
A10
A11
Vcc
Vcc
DQMB2
DQMB3
Vss
DQMB6
DQMB7
Vss
DQ12
DQ13
DQ14
DQ15
Vss
DQ44
DQ45
DQ46
DQ47
Vss
DQ24
DQ25
DQ26
DQ27
Vcc
DQ56
DQ57
DQ58
DQ59
Vcc
NC
NC
NC
NC
DQ28
DQ29
DQ30
DQ31
Vss
DQ60
DQ61
DQ62
DQ63
Vss
CLK0
Vcc
CKE0
Vcc
RAS
WE
CAS
CKE1
A12
CS0
CS1
SDA
SCL
NC
Vcc
Vcc
INFINEON Technologies
3
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
WE
CS0
CS1
CS WE
LDQM
CS WE
LDQM
CS WE
LDQM
CS WE
LDQM
DQMB0
DQMB4
DQ0-DQ7
DQ0-DQ7
DQ0-DQ7
UDQM
DQ32-DQ39
DQ0-DQ7
UDQM
DQ0-DQ7
DQMB1
DQMB5
UDQM
UDQM
DQ8-DQ15
DQ40-DQ47
DQ8-DQ15
D0
DQ8-DQ15
D4
DQ8-DQ15
D2
DQ8-DQ15
D6
CS WE
LDQM
CS WE
LDQM
CS WE
LDQM
CS WE
LDQM
DQMB2
DQMB6
DQ0-DQ7
DQ0-DQ7
DQ0-DQ7
UDQM
DQ0-DQ7
UDQM
DQ16-DQ23
DQ48-DQ55
UDQM
UDQM
DQMB3
DQMB7
DQ8-DQ15
D1
DQ8-DQ15
D5
DQ8-DQ15
D3
DQ8-DQ15
D7
DQ24-DQ31
DQ56-DQ63
E2PROM (256wordx8bit)
A0-A12, BA0, BA1
D0 - D7
VCC
VSS
SA0
SA1
SA2
D0 - D7
D0 - D7
C1-C4
SCL
SDA
RAS
CAS
CKE0
D0 - D7
D0 - D7
D0 - D7
4 SDRAM
4 SDRAM
CLK0
CLK1
note: all resistors are 10 Ohms
Block Diagram for two bank 32M x 64 SDRAM DIMM - Module
INFINEON Technologies
4
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
DC Characteristics
TA = 0 to 70 °C; VSS = 0 V; VDD,VDDQ = 3.3 V ± 0.3 V
Parameter
Symbol
Limit Values
Unit
min.
max.
Vcc+0.3
0.8
Input high voltage
VIH
VIL
2.0
– 0.5
2.4
V
Input low voltage
V
Output high voltage (IOUT = – 4.0 mA)
Output low voltage (IOUT = 4.0 mA)
VOH
VOL
II(L)
–
V
–
0.4
V
Input leakage current, any input
– 20
20
µA
(0 V < VIN < 3.6 V, all other inputs = 0 V)
Output leakage current
IO(L)
– 20
20
µA
(DQ is disabled, 0 V < VOUT < VCC)
Capacitance
TA = 0 to 70 °C; VDD = 3.3 V ± 0.3 V, f = 1 MHz
Parameter
Symbol Limit Values Unit
32M x 64
max.
Input capacitance (A0 to A11, BA0, BA1)
Input capacitance (RAS, CAS, WE, CKE0)
Input Capacitance (CLK0, CLK1)
Input capacitance (CS0)
CI1
CI2
CI3
CI4
CI5
CIO
TBD
TBD
TBD
TBD
TBD
TBD
8
pF
pF
pF
pF
pF
pF
pF
pF
Input capacitance (DQMB0-DQMB7)
Input / Output capacitance (DQ0-DQ63)
Input Capacitance (SCL,SA0-2)
Input/Output Capacitance
C
sc
sd
C
10
INFINEON Technologies
5
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
o
Operating Currents per memory bank (T = 0 to 70 C, Vdd = 3.3V ± 0.3V
A
(Recommended Operating Conditions unless otherwise noted)
Symb.
Note
Parameter & Test Condition
OPERATING CURRENT
-8A
trc=trcmin., tck=tckmin.
ICC1
TBD
TBD
mA
mA
mA
1
1
Ouputs open, Burst Length = 4, CL=3
All banks operated in random access,
all banks operated in ping-pong manner
to maximize gapless data access
PRECHARGE STANDBY CURRENT in tck = min.
Power Down Mode
ICC2P
mA
tck = Infinity
ICC2PS
ICC2N
TBD
TBD
mA
mA
1
1
CS =VIH (min.), CKE<=Vil(max)
PRECHARGE STANDBY CURRENT in tck = min.
Non-Power Down Mode
tck = Infinity
ICC2NS
ICC3N
ICC3P
ICC4
TBD
TBD
TBD
TBD
mA
mA
mA
1
1
1
CS = VIH (min.), CKE>=Vih(min)
NO OPERATING CURRENT
CKE>=VIH(min.)
CKE<=VIL(max.)
tck = min., CS = VIH(min),
active state ( max. 4 banks)
BURST OPERATING CURRENT
tck = min.,
Read command cycling
mA 1,2
AUTO REFRESH CURRENT
tck = min.,
Auto Refresh command cycling
ICC5
ICC6
1
TBD
TBD
mA
SELF REFRESH CURRENT
Self Refresh Mode, CKE=0.2V
L-version
mA
1
Notes:
1. These parameters depend on the cycle rate. These values are measured at 100 MHz for -8A modules.
Input signals are changed once during tck, excepts for ICC6 and for standby currents when tck=infinity.
2. These parameters are measured with continuous data stream during read access and all DQ toggling. CL=3
and BL=4 is assumed and the VDDQ current is excluded.
INFINEON Technologies
6
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
AC Characteristics 1)2)
TA = 0 to 70 °C; VSS = 0 V; VCC = 3.3 V ± 0.3 V, tT = 1 ns
Symbol
Unit
Parameter
Limit Values
-8A
PC100-322
min.
max.
Clock and Access Time
Clock Cycle Time
CAS Latency = 3
CAS Latency = 2
10
15
–
–
ns
ns
tCK
tCK
tAC
Clock Frequency
CAS Latency = 3
CAS Latency = 2
–
–
100
66
MHz
MHz
Access Time from Clock
CAS Latency = 3
CAS Latency = 2
2,
3
–
–
6
6
ns
ns
Clock High Pulse Width
tCH
tCL
tT
3
3
–
–
ns
ns
ns
Clock Low Pulse Width
Transition time
0.5
10
Setup and Hold Parameter
Input Setup Time
4
4
4
4
tIS
2
1
1
1
2
–
–
–
–
–
ns
Input Hold Time
tIH
ns
Power Down Mode Entry Time
Power Down Mode Exit Setup Time
Mode Register Set-up time
tSB
tPDE
tRSC
CLK
CLK
CLK
Common Parameters
Row to Column Delay Time
Row Precharge Time
Row Active Time
5
5
5
5
5
tRCD
tRP
tRAS
tRC
20
20
50
70
20
ns
ns
ns
ns
ns
100k
Row Cycle Time
–
Activate(a) to Activate(b) Command
period
tRRD
CAS(a) to CAS(b) Command period
tCCD
1
–
CLK
INFINEON Technologies
7
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
Symbol
Unit
Parameter
Limit Values
-8A
PC100-322
min.
max.
Refresh Cycle
Refresh Period (8192 cycles)
Self Refresh Exit Time
tREF
–
1
64
ms
tSREX
CLK
Read Cycle
Data Out Hold Time
tOH
tLZ
3
0
3
–
–
–
8
2
ns
2
Data Out to Low Impedance Time
Data Out to High Impedance Time
DQM Data Out Disable Latency
ns
tHZ
ns
tDQZ
CLK
Write Cycle
Data Input to Precharge
(write recovery)
tWR
2
0
–
–
CLK
CLK
DQM Write Mask Latency
tDQW
INFINEON Technologies
8
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
Notes:
1. An initial pause of 100µs is required after power-up, then a Precharge All Banks command must
be given followed by 8 Auto Refresh (CBR) cycles before the Mode Register Set Operation can
begin.
2. AC timing tests have V = 0.4 V and V = 2.4 V with the timing referenced to the 1.4 V crossover
il
ih
point. The transition time is measured between V and V . All AC measurements assume t =1ns
ih
il
T
with the AC output load circuit shownSpecified tac and toh parameters are measured with a 50
pF only, without any resistive termination and with a input signal of 1V / ns edge rate between
0.8V and 2.0 V.
.
tCH
2.4 V
0.4 V
CLOCK
tT
tCL
tHOLD
tSETUP
INPUT
1.4 V
tAC
tAC
tLZ
tOH
I/O
50 pF
OUTPUT
1.4 V
tHZ
Measurement conditions for
tac and toh
SPT03404
3. If clock rising time is longer than 1ns, a time (t -0.5) ns has to be added to this parameter.
T
4. If t is longer than 1ns, a time (t -1) ns has to be added to this parameter.
T
T
5. Any time that the refresh Period has been exceeded, a minimum of two Auto (CRB) Refresh
commands must be given to “wake-up“ the device.
6. Self Refresh Exit is a synchronous operation and begins on the 2nd positive clock edge after
CKE returns high. Self Refresh Exit is not complete until a time period equal to tRC is satisfied
once the Self Refresh Exit command is registered.
7. Referenced to the time which the output achieves the open circuit condition, not to output voltage
levels.
INFINEON Technologies
9
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
Serial Presence Detects:
A serial presence detect storage device - E2PROM - is assembled onto the module. Information about the module
configuration, speed, etc. is written into the E2PROM device during module production using a serial presence
detect protocol ( I2C synchronous 2-wire bus)
SPD-Table:
Byte#
Description
SPD Entry
Value
Hex
32Mx64
-8A
0
1
2
3
Number of SPD bytes
Total bytes in Serial PD
Memory Type
128
256
80
08
04
0D
SDRAM
Number of Row Addresses
(without BS)
4
5
Number of Column Addresses
Number of DIMM Banks
Module Data Width
09
02
40
00
01
A0
60
2
64
6
7
Module Data Width (cont’d)
Module Interface Levels
SDRAM Cycle Time at CL=3
0
8
LVTTL
10.0 ns
6.0 ns
9
10
SDRAM Access time from Clock at
CL=3
11
12
Dimm Config (Error Det/Corr.)
Refresh Rate/Type
none
00
82
Self-Refresh,
7.8µs
13
14
15
SDRAM width, Primary
10
00
01
Error Checking SDRAM data width
n/a / x8
Minimum clock delay for back-to-
back random column address
tccd = 1 CLK
16
17
18
19
20
Burst Length supported
Number of SDRAM banks
Supported CAS Latencies
CS Latencies
1, 2, 4 & 8
2
0F
04
06
01
01
2, & 3
CS latency = 0
WE Latencies
Write latency=
0
21
22
SDRAM DIMM module attributes
SDRAM Device Attributes :General
SDRAM Cycle Time at CL = 2
non buffered/
non reg.
00
0E
Vcc tol +/-
10%
23
24
12.0 ns
6.0 ns
F0
60
SDRAM Access Time from Clock at
CL=2
25
26
SDRAM Cycle Time at CL = 1
not supported
not supported
FF
FF
SDRAM Access Time from Clock at
CL=1
27
Minimum Row Precharge Time
20 ns
14
INFINEON Technologies
10
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
SPD-Table (cont’d):
Byte#
Description
SPD Entry
Value
Hex
32Mx64
-8A
28
Minimum Row Active to Row Active
delay
20 ns
14
29
30
31
32
33
34
35
Minimum RAS to CAS delay
Minimum Ras pulse width
Module Bank Density (per bank)
SDRAM input setup time
20 ns
60 ns
128MB
2 ns
14
32
20
20
10
20
10
FF
12
D5
FF
SDRAM input hold time
1 ns
SDRAM data input setup time
SDRAM data input hold time
2 ns
1 ns
36-61 Superset information
62
63
SPD Revision
Revision 1.2
Checksum for bytes 0 - 62
64- Manufactures’s information (optional)
125
126 Frequency Specification
127 Details
PC100
64
C7
FF
128+ Unused storage locations
INFINEON Technologies
11
HYS64V32220GD(L)-8A
PC100 144 pin SO-DIMM SDRAM Modules
64 MByte SO-DIMM Module package
(144 pin, dual read-out, single in-line memory module)
67,6
63,6
3.8
1
59
2.6
4.6
61
143
144
1±
0.1
3.3
23.2
32.8
±0.1
1.5
60
1.8
3.7
2
62
Detail of Contacts
±0.05
0.6
0.8
GLD09138
INFINEON Technologies
12
厂商 型号 描述 页数 下载

INFINEON

 		HYS64-72V2200GU-8 3.3V 2M ×64 /72- 1位BANK SDRAM模块3.3V 4M ×64 /72- 2位BANK SDRAM模块[ 3.3V 2M x 64/72-Bit 1 BANK SDRAM Module 3.3V 4M x 64/72-Bit 2 BANK SDRAM Module ] 17 页

INFINEON

 		HYS64-74V8200GU 3.3 V 8M ×64 /72- 1位银行SDRAM模块3.3 V 16M ×64 /72- 2位银行SDRAM模块[ 3.3 V 8M x 64/72-Bit 1 Bank SDRAM Module 3.3 V 16M x 64/72-Bit 2 Bank SDRAM Module ] 17 页

INFINEON

 		HYS6472V16200GU 3.3 V 16M ×64 /72-位SDRAM模块3.3 V 32M ×64 /72-位SDRAM模块3.3 V 64M ×64 /72-位SDRAM模块[ 3.3 V 16M x 64/72-Bit SDRAM Modules 3.3 V 32M x 64/72-Bit SDRAM Modules 3.3 V 64M x 64/72-Bit SDRAM Modules ] 17 页

INFINEON

 		HYS6472V4200GU 3.3V 4M ×64 /72- 1位BANK SDRAM模块3.3V 8M ×64 /72- 2位BANK SDRAM模块[ 3.3V 4M x 64/72-Bit 1 BANK SDRAM Module 3.3V 8M x 64/72-Bit 2 BANK SDRAM Module ] 15 页

INFINEON

 		HYS64D128020GBDL-6-A [ DDR DRAM Module, 128MX64, 0.7ns, CMOS, SO-DIMM-200 ] 11 页

ETC

 		HYS64D128020GBDL-7-A ？ 1GB （ 1024Mx64 ） PC2100 2银行？\n[ ?1GB (1024Mx64) PC2100 2-bank? ] 11 页

INFINEON

 		HYS64D128020GU-7-A 2.5 V 184针无缓冲DDR- SDRAM我模块[ 2.5 V 184-pin Unbuffered DDR-I SDRAM Modules ] 18 页

INFINEON

 		HYS64D128020GU-8-A 2.5 V 184针无缓冲DDR- SDRAM我模块[ 2.5 V 184-pin Unbuffered DDR-I SDRAM Modules ] 18 页

QIMONDA

 		HYS64D128020GU-8-A [ DDR DRAM Module, 128MX64, 0.8ns, CMOS, PDMA184 ] 18 页

INFINEON

 		HYS64D128021 200针的小型双列直插式内存模块[ 200-Pin Small Outline Dual-In-Line Memory Modules ] 23 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.229586s
