EZPE50117MTA

型号：

EZPE50117MTA

品牌：

PANASONIC[ PANASONIC ]

页数：

8 页

PDF大小：

363 K

下载PDF手册
Plastic Film Capacitors
Metallized Polypropylene Film Capacitors
Type: EZPE Series
■Features
High safety, Self-healing and Self-protecting function built-in
Long product life, High reliability
Low loss, Low ESR
Flame retardant (Case and sealing resin)
•
•
•
•
RoHS directive compliant
•
■Recommended Applications
For DC filtering, DC link circuit
Solar inverters
Wind power generation
Industrial power supplies
Inverter circuit in appliances (Air Conditioners etc.)
•
•
•
•
■Construction
Dielectric
Electrodes
Plastic case
Sealing
: Polypropylene film
: Metallized dielectric with segmented pattern
: UL94 V-0
: UL94 V-0
: Tinned wires,2-pin and 4-pin versions
•
•
•
•
•
Terminals
■Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
Z
P
E
T
A
Product code
Dielectric & Rated voltage
construction
Capacitance
Pin type Suffix
Suffix
50 500 VDC
80 800 VDC
L
M
2-pin type
4-pin type
1B 1100 VDC
1D 1300 VDC
■Specifications
(TC) (*1)
Category temperature range
–40 ˚C to +85 ˚C
500 VDC, 800 VDC, 1100 VDC, 1300 VDC
(Derating of rated voltage by more than 70 ˚C (*3))
(V
R) (*2)
Rated voltage
500 VDC
800 VDC
1100 VDC
1300 VDC
10 %
10 µF to 110 µF
10 µF to 60 µF
10 µF to 40 µF
10 µF to 25 µF
(C )
R
Rated capacitance
Capacitance tolerance
✕
Between terminals:Rated voltage. (VDC) 150 % 10 s
Withstanding DC voltage
Insulation resistance (CR)
Terminal to case:2110 VAC 10 s
>
CR 10000 Ω · F (20 ˚C, 500 VDC, 60 s)
=
*1:The temperature of capacitor surface (case)
*2:Use for DC voltage only
*3:Refer to the page of “ DC voltage derating ”
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
－ FC73 －
Plastic Film Capacitors
■Dimensions in mm (not to scale)
Marking
P1±1
Marking
P1±1
P2±1
φ±0.2
φ±0.2
Marking(ex.)
Panasonic
(a)
(b)
DC
V
μF
L±0.5
L±0.5
(a)ꢀRated voltage
(b)ꢀCapacitance
(c)ꢀLot No.
(c)
■Rating, Dimensions & Quantity / Ammo Box
●Type EZPE Rated voltage : 500 VDC at 70 ℃ ( 450VDC at 85 ℃ )
Dimensions (mm)
Permissible current
typ
ESR
tanδ
MOQ
[pcs]
(*5)
dv/dt
µs
R
C .
Mass
[ｇ]
Peak
RMS
Part No.
[mΩ]
[%]
Current Current
(µF)
[V/
]
W
H
L
P1 P2
φ
o-p
[A ]
(*1)
rms
(*2)
[A
]
(*3)
(*4)
EZPE50106LTA
EZPE50156LTA
EZPE50206LTA
EZPE50256LTA
EZPE50306MTA
EZPE50356MTA
EZPE50406MTA
EZPE50456MTA
EZPE50506MTA
EZPE50556MTA
EZPE50606MTA
EZPE50656MTA
EZPE50706MTA
EZPE50756MTA
EZPE50806MTA
EZPE50856MTA
EZPE50906MTA
EZPE50956MTA
10 20 42 41.5 37.5
15 20 42 41.5 37.5
20 20 42 41.5 37.5
25 20 42 41.5 37.5
-
-
-
-
1.2
1.2
1.2
1.2
21
210
315
420
525
630
735
840
945
1050
1155
1260
910
5.0
7.5
9.5
22.0
14.8
11.0
8.8
7.0
6.2
5.4
4.9
4.4
4.1
3.9
6.8
6.5
6.0
5.7
5.4
5.1
4.9
4.7
4.4
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.44
0.44
0.44
0.44
0.44
0.44
0.44
0.44
0.44
45
45
44
43
43
83
82
81
80
21
21
21
21
21
21
21
21
21
21
14
14
14
14
14
14
14
14
14
600
400
11.0
12.5
13.5
14.5
15.2
16.0
16.3
16.5
15.0
15.5
16.0
16.5
16.7
17.0
17.5
18.0
18.5
30 20 42 41.5 37.5 10.2 1.2
35 30 51 41.5 37.5 10.2 1.2
40 30 51 41.5 37.5 10.2 1.2
45 30 51 41.5 37.5 10.2 1.2
50 30 51 41.5 37.5 20.3 1.2
55 30 51 41.5 37.5 20.3 1.2
60 30 51 41.5 37.5 20.3 1.2
65 30 51 57.5 52.5 10.2 1.2
70 30 51 57.5 52.5 10.2 1.2
75 30 51 57.5 52.5 20.3 1.2
80 30 51 57.5 52.5 20.3 1.2
85 35 56 57.5 52.5 20.3 1.2
90 35 56 57.5 52.5 20.3 1.2
95 35 56 57.5 52.5 20.3 1.2
79
77
111
109
108
106
142
141
140
139
138
980
1050
1120
1190
1260
1330
1400
1540
200
EZPE50107MTA 100 35 56 57.5 52.5 20.3 1.2
EZPE50117MTA 110 35 56 57.5 52.5 20.3 1.2
*1:When rising temperature of capacitor surface by continuous peak current (included pulse current),
use within limit specified for temperature of capacitor surface and self heating temperature rise.
*2:Maximum RMS current @ 70 ℃, 10 kHz
Use within limit for self heating temperature rise at capacitor surface.
*3:Typical values @ 20℃, 10 kHz ESR : less than 2.5 × ESRtyp
*4:Maximum dissipation factor @20℃, 1 kHz
*5:Minimum order quantity consists of 4 packing units.
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
－ FC74 －
Plastic Film Capacitors
■Rating, Dimensions & Quantity / Ammo Box
●Type EZPE Rated voltage : 800 VDC at 70 ℃ ( 700VDC at 85 ℃ )
Dimensions (mm)
Permissible current
typ tanδ
ESR
MOQ
[pcs]
(*5)
dv/dt
µs
R
C .
Mass
[ｇ]
Peak
RMS
Part No.
[%]
[mΩ]
Current Current
(µF)
[V/
]
W
H
L
P1 P2
φ
o-p
[A ]
(*1)
rms
(*2)
(*4)
[A
]
(*3)
EZPE80106LTA
EZPE80156MTA
EZPE80206MTA
EZPE80256MTA
EZPE80306MTA
EZPE80356MTA
EZPE80406MTA
EZPE80456MTA
EZPE80506MTA
EZPE80556MTA
EZPE80606MTA
10 20 42 41.5 37.5
-
1.2
22
220
7.0
9.0
15.8
10.5
7.7
6.4
5.3
9.7
8.3
7.0
6.3
5.9
5.6
0.22
0.22
0.22
0.22
0.22
0.33
0.33
0.33
0.33
0.33
0.33
44
43
82
80
78
110
107
104
140
138
136
600
400
15 20 42 41.5 37.5 10.2 1.2
20 30 51 41.5 37.5 10.2 1.2
25 30 51 41.5 37.5 10.2 1.2
30 30 51 41.5 37.5 20.3 1.2
35 30 51 57.5 52.5 10.2 1.2
40 30 51 57.5 52.5 20.3 1.2
45 30 51 57.5 52.5 20.3 1.2
50 35 56 57.5 52.5 20.3 1.2
55 35 56 57.5 52.5 20.3 1.2
60 35 56 57.5 52.5 20.3 1.2
22
22
22
22
15
15
15
15
15
15
330
440
550
660
525
600
675
750
825
900
11.0
13.0
15.0
12.0
13.0
14.0
15.0
16.0
17.0
200
●Type EZPE Rated voltage : 1100 VDC at 70 ℃ ( 920VDC at 85 ℃ )
Dimensions (mm)
Permissible current
typ
ESR
tanδ
MOQ
[pcs]
(*5)
dv/dt
µs
R
C .
Mass
[ｇ]
Peak
RMS
Part No.
[mΩ]
[%]
Current Current
(µF)
[V/
]
W
H
L
P1 P2
φ
o-p
[A ]
(*1)
rms
(*2)
(*3)
(*4)
[A
]
600
400
EZPE1B106MTA
EZPE1B156MTA
EZPE1B206MTA
EZPE1B256MTA
EZPE1B306MTA
EZPE1B356MTA
EZPE1B406MTA
10 20 42 41.5 37.5 10.2 1.2
15 30 51 41.5 37.5 10.2 1.2
20 30 51 41.5 37.5 20.3 1.2
25 30 51 57.5 52.5 10.2 1.2
30 30 51 57.5 52.5 20.3 1.2
35 35 56 57.5 52.5 20.3 1.2
40 35 56 57.5 52.5 20.3 1.2
54
540
7.0
8.5
10.0
8.0
9.0
10.0
11.0
12.3
8.2
6.3
10.7
8.5
7.2
0.20
0.20
0.20
0.28
0.28
0.28
0.28
43
80
76
107
103
137
134
54
54
35
35
35
35
810
1080
875
1050
1225
1400
200
6.5
●Type EZPE Rated voltage : 1300 VDC at 70 ℃ ( 1100VDC at 85 ℃ )
Dimensions (mm)
Permissible current
typ tanδ
ESR
MOQ
[pcs]
(*5)
dv/dt
µs
R
C .
Mass
[ｇ]
Peak
RMS
Part No.
[%]
[mΩ]
Current Current
(µF)
[V/
]
W
H
L
P1 P2
φ
o-p
[A ]
(*1)
rms
(*2)
(*4)
[A
]
(*3)
400
200
EZPE1D106MTA
EZPE1D156MTA
EZPE1D206MTA
EZPE1D256MTA
10 30 51 41.5 37.5 10.2 1.2
15 30 51 57.5 52.5 10.2 1.2
20 30 51 57.5 52.5 20.3 1.2
25 35 56 57.5 52.5 20.3 1.2
73
730
12.0
10.0
14.0
17.0
10.0
14.5
11.1
8.5
0.17
0.22
0.22
0.22
80
50
50
50
750
1000
1250
109
103
136
*1:When rising temperature of capacitor surface by continuous peak current (included pulse current),
use within limit specified for temperature of capacitor surface and self heating temperature rise.
*2:Maximum RMS current @ 70 ℃, 10 kHz
Use within limit for self heating temperature rise at capacitor surface.
*3:Typical values @ 20℃, 10 kHz ESR : less than 2.5 × ESRtyp
*4:Maximum dissipation factor @20℃, 1 kHz
*5:Minimum order quantity consists of 4 packing units.
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
－ FC75 －
Plastic Film Capacitors
■Permissible Conditions
●Permissible Voltage
・These capacitors are designed only for DC voltage, so should not be used for AC line.
・Use the peak voltage (Vo-p) within the rated voltage.
・Use the peak to peak voltage (Vp-p) within 0.2 x VR .
VR ≧ Vo-p
Vp-p = 0.2 × VR
Vo
●DC Voltage, Peak current and RMS current derating
Derating of voltage (Vo-p), RMS current (Arms), and peak current (Ao-p) according to the following diagram
when the temperature of the capacitor surface exceeds 70 ℃.
DC Voltage derating
Current derating
120%
100%
80%
60%
40%
20%
0%
Voltage ①
Voltage ②
60
65
70
75
80
85
90
95
100
60
65
70
75
80
85
90
95
100
Temperature of capacitor surface TC (℃)
Part Number Voltage Voltage
Temperature of capacitor surface TC (℃)
①
②
EZPE50 □□□□ TA DC500V
DC450V
□□□□
EZPE80
TA DC800V
DC700V
DC1100V DC920V
EZPE1B □□□□ TA
EZPE1D □□□□ TA DC1300V DC1100V
●Permissible self heating temperature rise
●Total cycles applied peak current
Permissible self heating temperature rise is
within following diagram when the temperature
of the capacitor surface exceeds 70 ℃.
120%
Total cycles applied peak current (Ao-p)
(including pulse current) are within following diagram.
100%
80%
60%
40%
20%
0%
100%
80%
60%
40%
20%
0%
60
65
70
75
80
85
90
95
100
10
100
1000
10000
100000
Total cycles
Temperature of capacitor surface TC (℃)
Part Number
EZPE50 □□□□ TA
□□□□
100% at70 36% at85
℃
℃
12
10
5
4.3
3.6
1.8
3.2
℃
℃
℃
℃
℃
℃
EZPE80
TA
℃
EZPE1B □□□□ TA
EZPE1D □□□□ TA
9
℃
Please consult Panasonic if your condition exceeds the above spec.
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
■Characteristics ＜Reference＞
●Type EZPE Rated voltage : 500 VDC at 70 ℃ ( 450VDC at 85 ℃ )
●Temperature Characteristics
Dissipation factor (typical curve)
Capacitance (typical curve)
at 1kHz
at 1kHz
10
5
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0
110uF
100uF
-5
-10
60uF
20uF
-60
-40
-20
0
20
40
60
80
100
120
-60
-40
-20
0
20
40
60
80
100
120
Temperature (℃)
Temperature (℃)
Insulation resistance (typical curve)
at 500VDC
1.E+07
1.E+06
1.E+05
1.E+04
1.E+03
1.E+02
1.E+01
1.E+00
-60 -40 -20
0
20
40
60
80
100 120
Temperature (℃)
●Frequency Characteristics
●Lifetime expectancy
Impedance vs. Frequency (typical curve)
Lifetime expectancy (Reference)
100
10
550
500
450
400
350
300
250
200
Unpredictable life time area
Tc=70℃
20uF
60uF
110uF
1
Tc=85℃
0.1
Tc=105℃
(I=0Arms)
0.01
0.001
1
10
100
1000
10000
1000
10000
100000
1000000
Lifetime expectancy (h)
Frequency (kHz)
* Life time : Reach ⊿C/C = - 10 % , Judgement of Panasonic
* 105℃ : Not guarantee voltage
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
■Characteristics ＜Reference＞
●Type EZPE Rated voltage : 800 VDC at 70 ℃ ( 700VDC at 85 ℃ )
●Temperature Characteristics
Dissipation factor (typical curve)
Capacitance (typical curve)
at 1kHz
at 1kHz
10
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
5
0
-5
60uF
45uF
30uF
10uF
-10
-60
-40
-20
0
20
40
60
80
100
120
-60 -40
-20
0
20
40
60
80
100 120
Temperature (℃)
Temperature (℃)
Insulation resistance (typical curve)
at 500VDC
1.E+07
1.E+06
1.E+05
1.E+04
1.E+03
1.E+02
1.E+01
1.E+00
-60 -40 -20
0
20
40
60
80
100 120
Temperature (℃)
●Frequency Characteristics
●Lifetime expectancy
Impedance vs. Frequency (typical curve)
Lifetime expectancy (Reference)
100
10
900
800
700
600
500
400
300
Unpredictable life time area
10uF
Tc=70℃
30uF
45uF
60uF
Tc=85℃
1
0.1
Tc=105℃
(I=0Arms)
0.01
0.001
1
10
100
1000
10000
1000
10000
100000
1000000
Lifetime expectancy (h)
Frequency (kHz)
* Life time : Reach ⊿C/C = - 10 % , Judgement of Panasonic
* 105℃ : Not guarantee voltage
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
■Characteristics ＜Reference＞
●Type EZPE Rated voltage : 1100 VDC at 70 ℃ ( 920VDC at 85 ℃ )
●Temperature Characteristics
Dissipation factor (typical curve)
Capacitance (typical curve)
at 1kHz
at 1kHz
10
5
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0
-5
-10
40uF
20uF
10uF
-60
-40
-20
0
20
40
60
80
100
120
-60
-40
-20
0
20
40
60
80
100
120
Temperature (℃)
Temperature (℃)
Insulation resistance (typical curve)
at 500VDC
1.E+07
1.E+06
1.E+05
1.E+04
1.E+03
1.E+02
1.E+01
1.E+00
-60 -40 -20
0
20
40
60
80
100 120
Temperature (℃)
●Frequency Characteristics
●Lifetime expectancy
Impedance vs. Frequency (typical curve)
Lifetime expectancy (Reference)
100
10
1200
Unpredictable life time area
1100
1000
900
800
700
600
500
400
℃
Tc=70
10uF
20uF
40uF
1
℃
Tc=85
0.1
℃
Tc=105
0.01
0.001
( I = 0Arms)
1
10
100
1000
10000
1000
10000
100000
1000000
Lifetime expectancy (h)
Frequency (kHz)
* Life time : Reach ⊿C/C = - 10 % , Judgement of Panasonic
* 105℃ : Not guarantee voltage
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
■Characteristics ＜Reference＞
●Type EZPE Rated voltage : 1300 VDC at 70 ℃ ( 1100VDC at 85 ℃ )
●Temperature Characteristics
Dissipation factor (typical curve)
Capacitance (typical curve)
at 1kHz
at 1kHz
10
1.0
0.9
0.8
5
0.7
0.6
0
0.5
0.4
0.3
-5
0.2
0.1
25uF
15uF
10uF
-10
0.0
-60
-40
-20
0
20
40
60
80
100
120
-60
-40
-20
0
20
40
60
80
100
120
Temperature (℃)
Temperature (℃)
Insulation resistance (typical curve)
at 500VDC
1.E+07
1.E+06
1.E+05
1.E+04
1.E+03
1.E+02
1.E+01
1.E+00
-60 -40 -20
0
20
40
60
80
100 120
Temperature (℃)
●Frequency Characteristics
●Lifetime expectancy
Impedance vs. Frequency (typical curve)
Lifetime expectancy (Reference)
100
10
1400
1300
1200
1100
1000
900
Unpredictable life time area
10uF
15uF
Tc=70℃
Tc=85℃
25uF
1
0.1
800
Tc=105℃
700
0.01
0.001
(I=0Arms)
600
500
1
10
100
1000
10000
1000
10000
100000
1000000
Lifetime expectancy (h)
Frequency (kHz)
* Life time : Reach ⊿C/C = - 10 % , Judgement of Panasonic
* 105℃ : Not guarantee voltage
D
esign, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
厂商 型号 描述 页数 下载

PANASONIC

 		EZPE1B106MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B156MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B206MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B256MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B306MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B356MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1B406MTA 金属化聚丙烯液膜电容器[ Metallized Polypropylene Film Capacitors ] 4 页

PANASONIC

 		EZPE1D106MTA [ Plastic Film Capacitors ] 3 页

PANASONIC

 		EZPE1D156MTA [ Plastic Film Capacitors ] 3 页

PANASONIC

 		EZPE1D206MTA [ Plastic Film Capacitors ] 3 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于达普

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：smail@ic72.com

服务时间：周一至周六 8:30-17:30

达普官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.188877s
