Part Number:
Status:
1200110238
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 5 Poles, M16x1.5 Mounting Threads, Female
(Straight), PCB Pins
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Series image - Reference only
Industrial Receptacles
120011
EU ELV
Not Relevant
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
PCB Mount
EU RoHS
China RoHS
Compliant with
Exemption 6(c)
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
UPC
883906175979
Physical
Coupling Type
Gender
Internal Thread
Female
Halogen-Free
Status
Keyway
Length
Single
N/A
Low-Halogen
For more information, please visit Contact US
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
Nickel-plated Brass
PG9
22.679/g
Straight
Back
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
5
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-20°C to +80°C
N/A
N/A
Search Parts in this Series
120011 Series
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R5J400013
Reference - Drawing Numbers
Sales Drawing
SD-120070-013
