Part Number:
Status:
1200700207
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) 5 Poles, Front Panel Mount Receptacle, 1/4" - 18 NPT Threads,
Female (Straight) to 22 AWG PVC Leads, 2.0m (6.56') Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
Series image - Reference only
LR6837
E152210
EU ELV
General
Not Relevant
Product Family
Series
Industrial Receptacles
120070
IP67
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
For more information, please visit Contact US
IP Rating
NEMA Rating
Overview
Product Name
Type
NEMA 6
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
78678828691
UPC
Physical
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Relevant
Not Reviewed
Coupling Type
Gender
Keyway
Internal Thread
Female
Single
Length
0.305m
Material - Component
Mounting Thread Size
Orientation
Gray Annodized Aluminum
1/4" - 18 NPT
Straight
Front
Search Parts in this Series
120070 Series
Panel Mount
Poles
5
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-20°C to +80°C
22
UL 1061
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R5A00A18M020
SD-120070-056
Reference - Drawing Numbers
Sales Drawing
