Part Number:
Status:
1200708173
EU ELV
Not Reviewed
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 5 Poles, M12x1 and M14x1 Mounting Threads,
Female (Straight) to 2.0m (6.56') Length
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Not Reviewed
For more information, please visit Contact US
General
Product Family
Series
IP Rating
NEMA Rating
Overview
Product Name
Type
Industrial Receptacles
120070
IP67
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
NEMA 6
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
887191160375
Search Parts in this Series
UPC
120070 Series
Physical
Coupling Type
Gender
External Thread
Male
Keyway
Single
Length
2.0m
Material - Component
Mounting Thread Size
Orientation
Panel Mount
Poles
Nickel-plated Brass
M14 x 1.0
Straight
Front
5
Temperature Range - Operating
Wire Size AWG
-20°C to +80°C
22
Wire/Cable Type
Leads, UL 1061
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R5E36E03M020
SD-120070-236
Reference - Drawing Numbers
Sales Drawing
