SMCG6036 thru SMCG6072A
and SMCJ6036 thru SMCJ6072A
Bidirectional Transient Voltage Suppressor
S C O T T S D A L E D I V I S I O N
DESCRIPTION
APPEARANCE
These surface mount Transient Voltage Suppressors (TVSs) are used for protecting
sensitive components requiring low clamping voltage levels. They are rated at high
current impulses typically generated by inductive switching transients. Other benefits
are achieved with low-profile surface mount J-bend or Gull-wing terminals for stress-
relief and lower weight. Its low-flat profile provides easier insertion or automatic
handling benefits compared to other MELF style packages. Options for screening
similar to JAN, JANTX, JANTXV, and JANS also exist by using MQ, MX, MV or MSP
prefixes respectively for part numbers and high reliability screening in accordance
with MIL-PRF-19500/507.
IMPORTANT: For the most current data, consult MICROSEMI’s website: http://www.microsemi.com
FEATURES
APPLICATIONS / BENEFITS
•
•
•
Working Standoff Voltages: 5.5 volts to 185 volts
Metallurgically bonded
Reliability data per JESD22-A108, JESD22-A104,
JESD22-A113-B, JESD22-A101-B, and JESD22-A102
Thermally efficient surface mount with J-bends or
Gull wings termination for stress relief (flat handling
surface and easier placement)
Options for screening in accordance with MIL-PRF-
19500/507 for JAN, JANTX, JANTXV, and JANS are
available by adding MQ, MX, MV, or MSP prefixes to
part numbers respectively. For example, designate a
MXSMCJ6036A for a JANTX screen.
•
•
For high reliability transient voltage suppression in
low profile surface mount locations requiring easy
placement and strain relief
Light weight for airborne or satellite applications
•
• Superior surge quality to protect from ESD and EFT
transients per IEC61000-4-2 and -4-4
•
•
Lightning surge protection per IEC61000-4-5 for Class
1 and 2 with source impedance of 42 Ohms as well as
Class 3 and 4 selectively at lower voltages (VWM) and
higher surge current (IPP) ratings herein
•
Protects sensitive components such as ICs, CMOS,
Bipolar, BiCMOS, ECL, DTL, T2L, etc.
MAXIMUM RATINGS
MECHANICAL AND PACKAGING
•
•
•
Operating temperature: -55°C to +150°C
• Molded epoxy package meets UL94V-0
• Terminals: solderable per MIL-STD-750
Method 2026. (max 260 °C for 10 sec.)
• Body marked with P/N without SMCJ or SMCG letters
(ie. 6036A, 6039, 6053, 6072A, etc.)
Storage temperature: -55°C to +150°C
1500 Watts of Peak Pulse Power at 10/1000 µs as
shown in Figure 3 (see Figure 1 for other tP values)
Thermal resistance, RθJL = 20°C/W
Impulse repetition rate (duty factor): 0.01%
5.0 Watt steady-state maximum power at TL =25°C
tclamping (0V to V(BR) min): less than 5 ns
•
•
•
•
• No polarity band is shown on these bi-directional types
• Weight: 0.25 grams (approximate)
• Tape & Reel packaging per EIA-481
(2500 units/reel)
ELECTRICAL CHARACTERISTICS @ 25oC (Test Both Polarities)
Maximum
Rated
Stand-off
Voltage
(Note 1)
VWM
Volts
5.5
Clamping
Voltage
@ IPP
(10/1000 µs)
VC
Maximum
Standby
Current
@ VWM
ID
Maximum
Peak Pulse
Current
(Fig. 2)
IPP
Maximum
Temperature
Coefficient
of V(BR)
αV(BR)
%/oC
MICROSEMI
Part Number
MICROSEMI
Part Number
Breakdown
Voltage*
Modified
“G”
Modified
“J”
V(BR)
@
I(BR)
mA
10
10
10
10
10
10
1
Bend Lead
SMCG6036
SMCG6036A
SMCG6037
SMCG6037A
SMCG6038
SMCG6038A
SMCG6039
SMCG6039A
SMCG6040
SMCG6040A
SMCG6041
SMCG6041A
Bend Lead
SMCJ6036
SMCJ6036A
SMCJ6037
SMCJ6037A
SMCJ6038
SMCJ6038A
SMCJ6039
SMCJ6039A
SMCJ6040
SMCJ6040A
SMCJ6041
SMCJ6041A
Volts
Volts
11.7
µA
A
6.75 - 8.25
7.13 - 7.88
7.38 - 9.02
7.79 - 8.61
8.19 - 10.00
8.65 - 9.55
1000
1000
500
128
.061
6.0
11.3
132
.061
6.5
12.5
120
.065
7.0
12.1
500
124
.065
7.0
13.8
200
109
.068
7.5
13.4
200
112
.068
8.0
9.0
9.5
9.9
-
-
-
11.0
10.5
12.1
15.0
50
100
.073
8.5
1
14.5
50
103
.073
8.5
1
16.2
10
93
.075
9.0
10.5 - 11.6
10.8 - 13.2
11.4 - 12.6
1
15.6
10
96
.075
9.0
1
17.3
5
87
.078
10.0
1
16.7
5
90
.078
