ALUMINUM ELECTROLYTIC CAPACITORS
Wide Temperature Range
VZ series
(Through 100V only)
Small case sizes as same as VR series, but operating
over wide temperature range of –55 to +105˚C.
Compliant to the RoHS directive (2011/65/EU).
P S
High Rippie Current
High Reliability
VZ
P J
Smaller
High
Temperature
VY
VR
Specifications
Item
Performance Characteristics
Category
–55 to +105˚C (6.3 to 100V) , –40 to +105˚C (160 to 400V), –25 to +105˚C (450V)
Temperature Range
Rated
Rated
6.3 to 450V
Voltage Range
0.1 to 33000µF
± 20% at 120Hz, 20˚C
Capacitance Range
Capacitance Tolerance
Rated voltage (V
)
6.3 to 100
160 to 450
After 1 minute's application of rated voltage,
<
After 1 minute's application of rated voltage, leakage current
is not more than 0.03CV or 4 (µA), whichever is greater.
I
CV 1000: = 0.1CV+40 (µA) or less
=
Leakage Current
After 1 minute's application of rated voltage,
CV > 1000: = 0.04CV+100 (µA) or less
After 2 minutes' application of rated voltage, leakage current
is not more than 0.01CV or 3 (µA), whichever is greater.
I
F
F
For capacitance of more than 1000µ , add 0.02 for every increase of 1000µ .
Measurement frequency : 120Hz at 20˚C
Rated voltage (V
)
6.3
10
16
25
35
50
63
100
160 to 315 350 to 450
Tangent of loss angle (tan δ)
δ
tan
(
MAX.
)
0.28
0.24
0.20
0.16
0.14
0.12
0.10
0.08
0.20
0.25
Measurement frequency : 120Hz
Rated voltage (V)
Z–25˚C / Z+20˚C
Z–40˚C / Z+20˚C
6.3
5
10
10
4
8
16
3
6
25
2
4
35
2
3
50
2
3
63
2
3
100 160 to 200 250 to 350 400
450
15
—
Stability at Low Temperature
2
3
3
4
4
8
6
10
Impedance ratio
ZT / Z20 (MAX.
)
Capacitance change
tan δ
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 1000 hours at 105°C.
Endurance
Leakage current
After storing the capacitors under no load at 105˚C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Shelf Life
Marking
Printed with white color letter on black sleeve.
Type numbering system (Example : 10V 330µF)
Radial Lead Type
1
2
3
4
5
6
7
8
9 10 11
(
)
Sleeve P.E.T.
φd
U V Z 1 A 3 3 1 M E D
Configuration
Capacitance tolerance (±20%)
Rated capacitance (330µF)
Rated voltage (10V)
Series name
Pressure
relief vent
(φ6.3up)
Type
MIN
MIN
4
+
MAX
15
L
Configuration
(mm)
25
Pb-free leadwire
φ D
φD
P
5
6.3
2.5
0.5
0.5
8
10
5.0
0.6
0.5
12.5
5.0
0.6
0.5
16
7.5
0.8
0.5
18
20
22
Pb-free PET sleeve
2.0
3.5
0.6
0.5
7.5 10.0 10.0 12.5
5
DD
ED
PD
HD
RD
φd
0.5
0.5
0.8
0.5
1.0
0.5
1.0
1.0
1.0
1.0
6.3
8 · 10
12.5 to 18
20 to 25
(L 20) 1.5
(L 20) 2.0
• Please refer to page 20 about the end seal configuration.
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
Dimension table in next page.
