SMD Zener Diode
CZRZ3V3B-HF Thru. CZRZ6V8B-HF
Voltage: 3.3 to 6.8 Volts
Power: 100mW
RoHS Device
Halogen Free
0201/DFN0603
Features
- 100mW Power Dissipation.
0.015(0.37)
0.011(0.27)
- Voltages : 3.3V, 4.7V, 5.1V, 5.6V, 6.8V
- High reliability.
0.026(0.67)
0.022(0.57)
- Designed for mounting on small surface.
- Extremely thin/leadless package.
Mechanical data
0.013(0.340)
0.011(0.275)
- Case: 0201/DFN0603 package,
molded plastic.
0.002(0.05)
REF.
- Terminals: Gold plated, Solderable per
0.017(0.435)
0.014(0.365)
MIL-STD-750, method 2026.
0.001(0.03)
REF.
- Polarity: Color band denotes cathode end.
- Mounting position: Any
0.012(0.295)
0.009(0.225)
Circuit diagram
0.008(0.195)
0.005(0.125)
0.008(0.195)
0.005(0.125)
Dimensions in inches and (millimeter)
Maximum Rating (at TA=25°C unless otherwise noted)
Symbol
Parameter
Maximum Forward Voltage Drop at IF = 10 mA
Maximum Power Dissipation at 25 °C
Junction Temperature
Value
0.9
Unit
VF
PD
TJ
V
mW
°C
100
150
Operating Temperature Range
Storage Temperature Range
Topr
Tstg
-55 to +125
-55 to +150
°C
°C
Company reserves the right to improve product design , functions and reliability without notice.
REV:B
Page 1
QW-JZ007
Comchip Technology CO., LTD.
