1SS344
SURFACE MOUNT SCHOTTKY BARRIER DIODE
WON-TOP ELECTRONICS
Pb
Features
Low Forward Voltage
L
Fast Switching Speed
PN Junction Guard Ring for Transient and
ESD Protection
A
For General Purpose Switching Applications
Plastic Material – UL Recognition Flammability
Classification 94V-0
B
C
M
E
D
SOT-23
Min
H
G
Dim
A
Max
0.51
1.40
2.50
1.05
0.61
2.05
3.05
0.15
1.10
0.61
0.178
0.37
1.19
2.10
0.89
0.45
1.78
2.65
0.013
0.89
0.45
0.076
Mechanical Data
B
Case: SOT-23, Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
K
C
D
J
E
G
H
Polarity: See Diagram
Weight: 0.008 grams (approx.)
Mounting Position: Any
Marking: H9
Lead Free: For RoHS / Lead Free Version,
Add “-LF” Suffix to Part Number, See Page 4
J
K
L
M
All Dimensions in mm
TOP VIEW
Maximum Ratings @TA=25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Non-Repetitive Peak Reverse Voltage
VRM
25
20
V
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VR
V
Maximum Forward Continuous Current
Average Rectified Output Current
IFM
IO
1500
500
mA
mA
A
Non-Repetitive Peak Forward Surge Current
Operating and Storage Temperature Range
@ t = 10ms
IFSM
5.0
TJ, TSTG
-55 to +125
°C
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 1)
PD
200
mW
Note: 1. Mounted on FR-4 PC board with minimum recommended pad layout.
© Won-Top Electronics Co., Ltd.
Revision: April, 2012
www.wontop.com
1
