ET-RXB-22
ASK OOK Receiver Module
www.eeant.com
ASK Superheterodyne Wireless Receiver Module (ET-RXB-22)
ET-RXB-22 is ASK Superheterodyne Wireless Receiver Module working in ISM band. It can directly connect to MCU I/O
or the Data Input Port on wireless decoder chip. Easily fulfil the function from Wireless signal to Data Receiving.
ET-RXB-22 can work with several module (one transmitter module and several receiver module) at the same time, and
have no interference to each other, and don't influence the receiving distance.
Key Feature
◆ Modulation Mode : ASK / OOK
◆ Operating Frequency : 433.92 Mhz
◆ Operating Voltage : 3.3~5.5 V
◆ Operating Current : 3.8~4.1 mA (5.0V)
◆ Data Rate : 2.4 Kbps
◆ Sensitivity : -107 dbm
◆ Operating Temperature : -30~+85 ℃
◆ Working Distance : 300 m
◆ Dimension : 30*8.5*5 mm
Application
◆ Car security system
◆ Remote keyless entry (RKE)
◆ Garage door controller
◆ Home security
◆ Wireless controller
◆ Automation system
EEant Technology CO.,LTD
RXB22 Super-heterodyne Receiver Module
